ARCHITECTURAL RAILING SYSTEMS
FHC ACHIEVE FGR Frameless Glass Railing System
®

The Next Generation
Dry Glaze Railing System
FHC ACHIEVE ®
See Section 1 Pages 8 to19 for
Series Glass Railing
®
FHC ACHIEVE Series Producf Line Details
Supports 1/2" to
9/16" Tempered and
Laminated Glass - New Innovative Design Maintains
Railing Industry Standard 4-1/8" Base Shoe Height
- Compatible With 1/2" Tempered Monolithic,
9/16", 11/16" and 13/16" Tempered Laminated Glass
- New Design - 40% Lighter Than Traditional Base Shoes
FHC’s Innovative Patent - Available in 10' or 20' Stock Lengths, Pre-Drilled or Undrilled
Pending “One Seal” 1SGA - Designed for Heavy Glass Railing and Windscreen Applications
Dual Purpose Gasket. Now - Custom Fabrication Services Available
You Can Pre-Load or Roll - 6063-T5 Aluminum Alloy ICC
in the Same Gasket
- FHC’s Innovative “One Seal” 1SGA Series
(See Page 19)
Gasket Makes Installations Easy. Installers
NEW and Designed For Use With Can Pre-Load Gasket Before Setting Glass
and Use the Same Gasket on the Inside to
ENGINEERED FHC’s Patent Pending Finish the Installation
DESIGN ACHIEVE Dry Glaze ESR-4814
®
Shim Set Technology
NOW 40% LIGHTER (See Page 13)
FHC’s Tested and
Engineered Profile is 40%
Lighter Than Traditional
Base Shoes

Field Drilling Base Shoe
Just Got Easier With Our A1M Series A3M Series A5M Series
Engineered Hollow Profile
1/2" - 9/16" Glass 11/16" Glass 13/16" Glass
Design On All Base Shoe Railing Base Shoe Railing Base Shoe Railing Base Shoe
Profiles

FHC ACHIEVE® Base Shoe FHC ACHIEVE®
Cladding and End Caps Installation and

Removal Tool Kit
AEC1 End Cap for A1M Series
AEC3 End Cap for A3M Series ITEM NO. ACH1K
AEC5 End Cap for A5M Series Extremely Simple
and Easy to Use

FHC ACHIEVE Shim Set
®
- Patent Pending
ASC10 ASC1F ASC0F - 10 Shims Per Box
Standard Inside Outside
ACH2G For 1/2" to 11/16" Glass
Cladding Fascia Cladding Fasci Cladding
ACH3G For 13/16" Glass
