SECTION 3 FHC FRAMELESS POINT SUPPORTED RAILING STANDOFF SYSTEMS

FHC Frameless Point Supported Railing Standoff Systems

FHC Glass Railing Round
1-3/4"
Standoff Base With Cap
- For 1/2" to 13/16" Tempered Glass
- 2" Diameter
- Drilled and Tapped for 3/8"-16 Fastener 1"
- 316 Grade Stainless Steel
- Can be Custom Manufactured
to Your Specifications
- Requires One 3/4" (19 mm)
Diameter Hole in Glass

3/8" 1" or 1-3/4"
ITEM NO. RS2X134

ITEM NO. RS2X1
2" See Pages 60 - 61 for
Diameter
Replacement Caps,
Grommets & Anchors

Includes 3/8"-16
2" Long Threaded
Includes (2) Rigid Vinyl Gaskets Stud
1" LENGTH 1-3/4" LENGTH
and (1) Grommet ITEM NO. ITEM NO. FINISH
RS2X1BS RS2X134BS Brushed Stainless
RS2X1PS RS2X134PS Polished Stainless
RS2X1MB RS2X134MB Matte Black
Minimum Order: 1 Each.

FHC Glass Railing Square
1"
Standoff Base With Cap

- For 1/2" to 13/16" Tempered Glass
1-3/4"
- 2" Square
- Two-Piece Cap Design Ensures Proper
Alignment With Standoff Base
- Drilled and Tapped for 3/8"-16 Fastener
- 316 Grade Stainless Steel
- For 1/2" to 13/16" Thick Tempered Glass
- Can Be Custom Manufactured to
Your Specifications
- Requires One 3/4" (19 mm)
Diameter Hole in Glass
ITEM NO. SS2X1
3/8"
1" or 1-3/4"
ITEM NO. SS2X134

See Pages 60 - 61 for
Replacement Caps,
2" Grommets & Anchors
Square

Includes 3/8"-16 1" LENGTH 1-3/4" LENGTH
2" Long Threaded ITEM NO. ITEM NO. FINISH
Stud SS2X1BS SS2X134BS Brushed Stainless
Includes (2) Rigid Vinyl Gaskets SS2X1PS SS2X134PS Polished Stainless
and (1) Grommet
SS2X1MB SS2X134MB Matte Black
Minimum Order: 1 Each.
