FHC FRAMELESS POINT SUPPORTED RAILING STANDOFF SYSTEMS SECTION 3
FHC Frameless Point Supported Railing Standoff Systems

FHC Glass Railing Round Standoffs FHC Glass Railing Square Standoffs
With Mounting Plate With Mounting Plate

- For 1/2" to 13/16" Tempered Glass See Pages 60 - 61 for - For 1/2" to 13/16" Tempered Glass See Pages 60 - 61 for
- 4" x 8" Wall Mount Plate With Replacement Caps, - 4" x 8" Wall Mount Plate With Replacement Caps,
2" Diameter Standoffs 2" Square Standoffs Spaced
Spaced 4" Center-to-Center Gaskets, Grommets 4" Center-to-Center Gaskets, Grommets
- 1-3/4" Standoff Length & Anchors - 1-3/4" Standoff Length & Anchors
- 316 Grade Stainless Steel - 2-Piece Cap Design
- Includes Caps, Rigid Vinyl Gaskets Ensures Proper Alignment With (6) 7/16" Dia. Mounting
and Grommets Standoff Base Holes. Anchor Bolts Sold
- Can be Custom Manufactured to Your - 316 Grade Stainless Steel Separately (See Page 61)
Specifications - Can be Custom Manufactured
- Requires Two 3/4" (19 mm) 4" to Your Specifications 4"
Diameter Holes in Glass - Requires Two 3/4" (19 mm)
Diameter Holes in Glass
Requires 1-3/4"
3/4" Diameter Projection Requires 1-3/4"
Hole 3/4" Diameter
Through Hole
Glass Through
Glass
C L
C L
4" 8" 8"
4"
C L
C L

1-1/2"
Minimum 1-1/2"
Minimum
ITEM NO. FINISH ITEM NO. FINISH
RS20BS Brushed Stainless SS20BS Brushed Stainless
RS20PS Polished Stainless SS20PS Polished Stainless
RS20MB Matte Black 3/8" Thick SS20MB Matte Black 3/8" Thick
Stainless Steel Stainless Steel
Minimum Order: 1 Each. Minimum Order: 1 Each.

Typical Railing Standoff Layout See Section 2 (pages 34-50)
for Top Rail options
60" Recommended Maximum
Glass Panel Width

See Section 5 (pages 86-98)
for Handrail options

42"
Overall
Height
Varies Line of Finished Floor

C L C L C L
6" Equal Equal 6"

1.5" Minimum
