SECTION 3 FHC FRAMELESS POINT SUPPORTED RAILING STANDOFF SYSTEMS

FHC Frameless Point Supported Railing Standoff Systems

FHC Round Replacement FHC Square Replacement 3/8"
3/8"
Cap for Glass Railing Cap for Glass Railing
Standoff Standoff

- 2" Outside Diameter - 2" x 2" Square
- Used With FHC Standoff - Used With FHC Standoff
Railing System Railing System
- 316 Grade - 316 Grade Stainless Steel
Stainless Steel

Each Cap Assembly Includes: FHC 2" DIAMETER REPLACEMENT CAP Each Cap Assembly Includes: FHC 2" SQUARE REPLACEMENT CAP
• 1 Each Cap ITEM NO. FINISH • 1 Each Cap (Two-Piece Design) ITEM NO. FINISH
• 1 Each 3/8"-16 Allen Screw RSCAP2BS Brushed Stainless • 1 Each 3/8"-16 Allen Screw SSCAP2BS Brushed Stainless
• 1 Each Grommet RSCAP2PS Polished Stainless • 1 Each Grommet SSCAP2PS Polished Stainless
• 2 Each Black Rigid RSCAP2MB Matte Black • 2 Each Black Rigid SSCAP2MB Matte Black
Vinyl Gaskets Vinyl Gaskets
Minimum Order: 1 Each. Minimum Order: 1 Each.
FHC 2" Diameter Replacement
Gasket & Grommet Set ITEM NO. DESCRIPTION
RSRG1 Neoprene Material
- Used With FHC Round Standoffs RSRG1V Rigid Vinyl Material
- Includes Two Gaskets and One Grommet Minimum Order: 1 Pack.
- Available in Neoprene or Rigid Vinyl
5/8" Diameter O.D.

FHC 2" x 2" Square Replacement
Gasket & Grommet Set
- 2" x 2" Square Black Neoprene Gaskets
ITEM NO. DESCRIPTION
- 5/8" Diameter Grommet
SSRG1 Neoprene Material
- Used with FHC 2" Square Standoffs SSRG1V Rigid Vinyl Material
- Includes Two Gaskets and One Grommet Minimum Order: 1 Pack.
- Available in Neoprene or Rigid Vinyl 5/8" Diameter O.D.
FHC Cap Wrench for FHC Shims for FHC Standoff Railing
2" Diameter Standoffs Glass Rail Standoffs Trim Rings
- Used to - 2" Outside Diameter - Used With
Loosen or - Used to Shim and Align Standoffs 2" Diameter Standoffs
Tighten 2" - For FHC Standoff Railing System - 3" Outside Diameter
Standoff - 1/8" Thickness
Caps - Available in Two Sizes: 1/16" and 1/8" Thick
- 10 Shims Per Pack
Shim

2" 3"

Trim Ring
(Standoff Base and
Cap Sold Separately)
1/16" or 1/8" Thick
1/16" 1/8" ITEM NO. FINISH
THICKNESS THICKNESS FINISH
ITEM NO. ITEM NO. RSTR2BS Brushed Stainless
RS16BS RS18BS Brushed Stainless RSTR2PS Polished Stainless
ITEM NO. RSW2 RS16PS RS18PS Polished Stainless RSTR2MB Matte Black
Minimum Order 1 Each RS16MB RS18MB Matte Black Minimum Order: 1 Each.
Minimum Order:1 Pack.
visit fhc-usa.com to search for
Rail Standoffs
