FHC GLASS GATE SYSTEMS AND HARDWARE SECTION 7
FHC Glass Gate Patch Hardware

FHC European Top or Bottom Patch Fitting

- European 2-9/16" Pivot Setback
- Use With Top PF303 or Bottom PF301 6-7/16"
Inserts (Sold Separately)
- Gaskets for use With 3/8" or
1/2" Tempered Glass ITEM NO. PF303
- Available in Five Finishes Top Pivot Insert
- Works With Bottom Hydraulic (Sold Separately)
Patch Fitting (See Below)
- Requires One 3/4" Hole and 2"
Cutout in Glass
Chat With FHC On Our Website
ITEM NO. FINISH to Get Real Time Expert Support
EPF201BS Brushed Stainless from Knowledgeable Reps
EPF201PS Polished Stainless
ITEM NO. PF301
EPF201SA Satin Anodized Bottom Pivot Insert
EPF201MB Matte Black Chat With Us! (Sold Separately)
EPF201DU Dark Bronze
Minimum order: 1 each.
FHC Hydraulic Patch Fitting

- European 2-9/16" - For Interior Use
Pivot Setback - Surface Mount Design, 1-5/8"
- For 3/8", 1/2" or 9/16" No Floor Cutout
Tempered Glass Required
- Hold-Open and No Hold- - Use With EPF201 Series 7-3/16"
Open Models Available Top Patch Fitting 2-3/4"
- 40" Recommended Max With 2-9/16" Pivot
Door Widths Setback (See Above) Non - Handed
- 220 Lb. Max Weight - Requires Cutout in Glass
Limitation

ITEM NO. DESCRIPTION FINISH
HPF90H0BS 90° HOLD-OPEN Brushed Stainless
HPF90H0PS 90° HOLD-OPEN Polished Stainless
HPF90H0SA 90° HOLD-OPEN Satin Anodized
HPF90H0MB 90° HOLD-OPEN Matte Black 2-9/16" Pivot
HPF90NH0BS 90° NO HOLD-OPEN Brushed Stainless Setback Base Plate
HPF90NH0PS 90° NO HOLD-OPEN Polished Stainless 1-13/16" W x 4-7/8"
HPF90NH0SA 90° NO HOLD-OPEN Satin Anodized L x 1/2" H
HPF90NH0MB 90° NO HOLD-OPEN Matte Black
Minimum order: 1 each.
FHC North American
Top or Bottom Patch Fitting
- 2-3/4" Pivot Setback 6-7/16"
- Gaskets for Use With 3/8" or
1/2" Tempered Glass
- Use With Top PF303 or Bottom ITEM NO. PF303
Top Pivot Insert
PF301 Inserts (Sold Separately) (Sold Separately)
- Requires One 3/4" Diameter Hole
and Cutout in Glass
- Five Architectural Finishes Available 2"
ITEM NO. FINISH 2-3/4" Pivot
PF201BS Brushed Stainless Setback
PF201PS Polished Stainless
PF201SA Satin Anodized ITEM NO. PF301
PF201MB Matte Black ITEM NO. PF304 Bottom Pivot Insert
PF201DU Dark Bronze Pivot Insert (Sold Separately)
Minimum order: 1 each. (Sold Separately)
