SECTION 4 FHC F-SERIES HEAVY-DUTY STAINLESS STEEL POST RAILING SYSTEMS
FHC F1 Series Railing Posts

FHC F1 Series Blank Railing Posts

- 1.9" Outside Diameter
- 54" Tall Blank Post Includes
Adjustable Height Fixed or Swivel
Stem With Saddle
- No Additional Welding Necessary
- Blank Post Designed to be Cut
and Fabricated in the Field 54"
- Available in Brushed and Polished
Stainless Steel Finishes
- Stanchions, Cover Plates,
Fascia Bracket, and Glass Fittings
Sold Separately Blank Post
With Fixed Stem Shown Blank Post are Available With
an Adjustable Height Fixed or
Swivel Stem for Ramp or Stair Areas. 3/4" of
FHC F1 SERIES BLANK POST WITH FIXED STEM AND SADDLE Vertical
Adjustment
ITEM NO. DESCRIPTION FINISH
F154FBS 1.9" Diameter Blank Post With Fixed Stem Brushed Stainless
F154FPS 1.9" Diameter Blank Post With Fixed Stem Polished Stainless
Minimum Order: 1 Each.
FHC F1 SERIES BLANK POST WITH SWIVEL STEM AND SADDLE
ITEM NO. DESCRIPTION FINISH
F154SBS 1.9" Diameter Blank Post With Swivel Stem Brushed Stainless
F154SPS 1.9" Diameter Blank Post With Swivel Stem Polished Stainless
Minimum Order: 1 Each. Blank Post Fixed Stem & Saddle Swivel Stem & Saddle
FHC F1 Series Railing Post - 1.9" Outside Diameter - Available in Brushed and Polished
Configurations - Pre-Fabricated 42" Post Stainless Steel Finishes
- Includes Welded Flange, Cover Plates, - Powder Coat Options Also Available
Fixed Stem and Saddle
End Post 180 Degree 135 Degree 90 Degree
Center Post Angle Post Corner Post

1-3/4"
6"
Each Post Includes a
Adjustable Fixed Stem
and Saddle

See Pages 102-103
Drilled & Tapped 3/8"-16 For Glass Fitting Linear Brushed Stainless
Holes For Glass Fittings Options Steel Finish Shown
41"

Ø4-7/8" Ø4-7/8" Ø4-7/8" Ø4-7/8"

135˚
6" 90˚

END POST 180 DEGREE CENTER POST 135 DEGREE ANGLE POST 90 DEGREE CORNER POST
ITEM NO. FINISH ITEM NO. FINISH ITEM NO. FINISH ITEM NO. FINISH
F1E42BS Brushed Stainless F1C42BS Brushed Stainless F1A42BS Brushed Stainless F1942BS Brushed Stainless
F1E42PS Polished Stainless F1C42PS Polished Stainless F1A42PS Polished Stainless F1942PS Polished Stainless
Minimum Order: 1 Each. Minimum Order: 1 Each. Minimum Order: 1 Each. Minimum Order: 1 Each.
