FHC F-SERIES HEAVY-DUTY STAINLESS STEEL POST RAILING SYSTEMS SECTION 4
FHC F3 Series Railing Post Components

FHC 1" X 2" Narrow Rectangular Rail

- 1" x 2" Rectangular Profile 1/8" Wall
- 240" Length Thickness
- Available In Two Architectural Finishes 2" X 1" RECTANGULAR RAIL
- End Caps, Corners, Sleeves and Post 1" ITEM NO. FINISH
Components Sold Separately PR12BS Brushed Stainless
- Custom Fabrication Services Available. PR12PS Polished Stainless
Contact FHC Technical Sales for a Quote 2" Minimum Order: 1 Each.
Must Ship Common Carrier.
- 316 Grade Stainless Steel
FHC Swivel Stem for 1" x 2" FHC Fixed Stem for 1" x 2"
Narrow Rectangular Rail Narrow Rectangular Rail

- 1-3/4" Tall Swivel Stem - 1-3/4" Tall Fixed Stem
Ideal for Stair Installations - 3/4" Vertical Adjustment
- 3/4" Vertical Adjustment - Designed for use
- Designed for use 3/4" Vertical With PR12 1" x 2" 3/4" Vertical
With PR12 1" x 2" Adjustment Rectangular Tubing Adjustment
Rectangular Tubing and Swivel - Can be Welded
- Can be Welded Ability or Bonded Using
or Bonded Using Epoxy LT1324007
Epoxy LT1324007 (See Page 99)
(See Page 99) ITEM NO. FINISH - Saddle Sold Separately ITEM NO. FINISH
- Saddle Sold Separately PR12ASBS Brushed Stainless - 316 Grade Stainless Steel PR12FSBS Brushed Stainless
Polished Stainless
Polished Stainless
PR12FSPS
PR12ASPS
- 316 Grade Stainless Steel Minimum Order: 1 Each. Minimum Order: 1 Each.
FHC Floor Flange for 1" X 2" FHC Flange Cover Plate for 1" X 2"
Narrow Rectangular Pipe Rail Narrow Rectangular
Pipe Rail
- 3/8" Thick Mill 316
Grade Steel Stainless
- Designed to be Welded - Designed Fit Over 1"
on 1"x2" Rectangular PR12CF Flange or
Tubing PR12S Stanchion 5-3/16"
- Pre -Drilled With (4) - Use With FHC PR12 1"
9/16" Diameter Holes x 2" Rectangular 5-3/16"
5" 5" Pipe Rail
- 316 Grade Stainless
Steel ITEM NO. FINISH
ITEM NO. PR12CF PR12CVBS Brushed Stainless
Polished Stainless
PR12CVPS
Minimum Order: 1 Each
Minimum Order 1 Each
FHC Surface Mount Post Stanchion FHC Post Caps for
With 5" Square Base Heavy-Duty 1" X 2" Rectangular Pipe Rail
Solid Construction
- Stanchion Allows Installer to - Used on PR12AS/PR12FS When
Fabricate Post Without Welding Stem is Not Required
- 5" Tall Stanchion 9/16" - Install Using Epoxy LT1324007
- For 1" x 2" Rectangular 3/8" Diameter Holes (See Page 99)
Stainless Tubing Thick - 316 Grade Stainless Steel
- Install Using Epoxy LT1324007
(See Page 99)
- 316 Grade Stainless Steel
5" ITEM NO. FINISH
ITEM NO. PR12S 5" PR12CAPBS Brushed Stainless
Minimum Order: 1 Each PR12CAPPS Polished Stainless
Minimum Order 1 Each
