SECTION 3                                                     FHC ALUMINUM  STOREFRONTS AND ENTRANCES
                                                                                   ®
        FHC Commercial Door Offset Pivots


        FHC Commercial Door 3/4" Offset Pivots                                    Chat With FHC On Our Website
                                                                                  to Get Real Time Expert Support
                                                                                  from Knowledgeable Reps
                                Typical Mounting Offset Pivot
                                   of Header and Jamb                              Chat With Us!



                    Typical Elevation
                  Front and Side Views                                          Pivot
                                                                               Jamb

                                                                                                     Strike
                                                                                                     Jamb
                                                                           Threshold




                                             Pivot
                                            Jamb




                                                                          Typical Mounting Offset Pivot
                                                                            of Threshold and Jamb
                                          Standard
                                            Offset
                                             Pivot


        FHC Offset Pivot Set                                  FHC 25 Series
           -  3/4" Offset                                     Offset Pivot Hinge Set Flush
           -  Available in Aluminum                           With Frame Face
         and Dark Bronze
         Anodized Finish
           - Handed Not Reversible                               -  3/4" Offset
           -  Standard Pivot on FHC                              -  Available in
         Doors                                                 Aluminum and
                                                               Dark Bronze
                                                               Anodized Finish
                                                                 -  Handed Not
                                                               Reversible
















         LEFT HAND  RIGHT HAND                                 LEFT HAND  RIGHT HAND
         ITEM NO.  ITEM NO.  FINISH                            ITEM NO.  ITEM NO.  FINISH
         8163LHCA  8163RHCA  Clear Anodized                    FDP25LHA  FDP25RHA  Aluminum
         8163LHAA  8163RHAA  Dark Bronze Anodized              FDP25LHDU  FDP25RHDU  Dark Bronze Anodized
         Minimum order: 1 set.                                 Minimum order: 1 each.
