FHC GLASS GATE SYSTEMS AND HARDWARE SECTION 7
FHC Self-Closing Hinges

FHC Panorama Series Hydraulic
Self-Closing Wall Mount Hinges

- Designed for Self-Closing Gates or Doors

- For 3/8" or 1/2" Tempered Glass
- Dual Action
- Adjustable Closing Speed

- Hold Open and Non-Hold Open
Models Available Panorama Hinges
- Brushed or Polished Stainless Finishes Are Sold As a Set
- 316 Grade Stainless Steel
- Requires Glass Fabrication
- Maximum Door Width 40"
- Maximum Door Weight 132 Lbs.

WALL MOUNT HINGES
ITEM NO. MODEL FINISH Box Includes:
PAN1BS Non Hold Open Brushed Stainless • 1 Hydraulic Hinge
PAN1PS Non Hold Open Polished Stainless
PAN1HBS Hold Open Brushed Stainless • 1 Spring Hinge
PAN1HPS Hold Open Polished Stainless
Minimum Order: 1 Set.

FHC Panorama Series Hydraulic
Self-Closing 180 Degree
Glass-to-Glass Hinges

- Designed for Self-Closing Gates or Doors

- For 3/8" or 1/2" Tempered Glass
- Dual Action
- Adjustable Closing Speed

- Hold Open and Non-Hold Open
Models Available
- Brushed or Polished Stainless Finishes
- 316 Grade Stainless Steel
- Requires Glass Fabrication
- Maximum Door Width 40"
- Maximum Door Weight 132 Lbs.
Box Includes:
• 1 Hydraulic Hinge
• 1 Spring Hinge

Panorama Hinges Speed Adjustment
Are Sold As a Set
1. Fully Tighten the No. 1 and No. 2
Speed Adjustment Valves.
2. Loosen the No 1 and No 2 Valves by 1/4 Turn.
3. Adjust the No 2 Valve to Ideal Closing Speed.
180 DEGREE GLASS-TO-GLASS HINGES 4. Adjust the No 1 Valve to Ideal Closing Speed.
ITEM NO. MODEL FINISH 5. It's Suggested to Turn No More Than 1/4 Turn
Each Time You Adjust the Valves.
PAN2GBS Non Hold Open Brushed Stainless
PAN2GPS Non Hold Open Polished Stainless WARNING: Do Not Loosen the Speed Adjustment
PAN2HGBS Hold Open Brushed Stainless Screws Completely Out to Maintain Factory Standards
PAN2HGPS Hold Open Polished Stainless
and Ensure Proper Functioning.
Minimum Order: 1 Set.
