SECTION 1 FHC FRAMELESS GLASS RAILINGS
FHC ACHIEVE FGR Frameless Glass Railing System
®

FHC ACHIEVE Installation & ICC ®
®
Removal Tool Kit
- Extremely Simple and Easy to Use
®
- Designed For Use with FHC’s Revolutionary ACHIEVE
Shim Sets ESR-4814
®
- FHC’s ACHIEVE Tool Kit Includes Everything Needed for the
Installation and Removal Process
- Quality Heavy-Duty Stainless Steel Tools, Built to Last
- FHC’s Precision Engineered Tool Design Allows For
Accurately Measured Installs Every Time
- Works with Monolithic and Laminated SGP Tempered Glass
- For Use with Surface Mount, Fascia/Side Mount,
and Recessed Mount Base Shoe Applications
Everything You Need
- No More Messy Wet Set Cement
to Install or Remove
- U.S. Patent Pending
®
FHC ACHIEVE Shims
is Included in this Kit.
Typical Shim and Anchor Spacing

12" - 14" ACHIEVE
®
Shim Spacing
6" ITEM NO. ACH1K
Minimum Order 1 Each
KIT INCLUDES:
- Tool Bag - 2 Lb. Deadblow
- Installation Tool Hammer
- Removal Tool - Two Glass Staging
C L C L 12" Typical - Glass Setting Tool - Pads Vinyl Roller
Anchor Spacing

Heavy-Duty Heavy-Duty Glass Setting 2LB. Dead-Blow Glass Staging Vinyl Roller
Stainless Steel Stainless Steel Tool Hammer Pads Tool
Installation Tool Removal Tool

Fast & Easy Installation
1 2 3
Install Base Shoe,
1 Exterior Gasket &
Setting Block

Install Glass & Set Shims
2 Using Installation Tool

Apply Cladding &
3 Roll-In Interior Gasket
Using VRT17 Vinyl Roller
Tool to Finish the Install
