FHC FRAMELESS GLASS RAILINGS SECTION 1
FHC ACHIEVE FGR Frameless Glass Railing System
®
Supports 1/2" to ®
9/16" Tempered and
Laminated Glass
FHC’s Innovative Patent
Pending “One Seal” 1SGA
Dual Purpose Gasket. Now FHC A1M
You Can Pre-Load or Roll
in the Same Gasket
(See Page 19) Series
1/2" (12 mm) - 9/16" (13.52 mm)
Designed For Use With
FHC’s Patent Pending Glass Railing Base Shoe
ACHIEVE Dry Glaze
®
Shim Set Technology - New Innovative Design Maintains Railing
(See Page 13) Industry Standard 4-1/8" Base Shoe Height
- Compatible With 1/2" Monolithic and 9/16"
Laminated Tempered Glass Thickness Range:
.469" Min to .531" Max
ICC - New Design - 40% Lighter Than

Traditional Base Shoes
- 10' and 20' Stock Lengths Drilled or Undrilled
FHC’s Tested and

Engineered Profile is 40% - Designed for Heavy Glass Railing and
Lighter Than Traditional Windscreen Applications
ESR-4814 Base Shoes - Custom Fabrication Services Available
- 6063-T5 Aluminum Alloy
- FHC’s Innovative “One Seal” 1SGA Series Gasket
Makes Installations Easy. Installers Can Pre-Load
Field Drilling Base Shoe Gasket Before Setting Glass and Use the Same
Just Got Easier With Our
Gasket on the Inside to Finish Installation
Engineered Hollow Profile
Design On All Base Shoe
Profiles
See Page 18
for Cladding Options
A1M ACHIEVE ® SERIES ALUMINUM BASE SHOE
ITEM NO. DESCRIPTION
A1M10 Undrilled 120" Long
A1M10D Bottom Drilled 12" C.T.C. 120" Long
A1M10F Fascia Drilled 12" C.T.C. 120" Long
A1M20 Undrilled 240" Long
A1M20D Drilled 12" C.T.C. 240" Long ITEM NO. ACH2G
®
FHC ACHIEVE Glass Rail Shim ITEM NO. ACH1K
A1M20F Fascia Drilled 12" C.T.C. 240" Long ®
Set 10 Shim Sets Per Box ACHIEVE
Minimum Order: 1 Each. Must Ship Common Carrier. Installation Tool Kit
1-5/16" 1-5/16" 1-5/16"

4-1/8"

7/8"
4-1/8" 4-1/8"
9/16"
7/8"
13/16" 13/16"
13/16"
9/16"
2-13/16" 2-13/16" 2-13/16"
Undrilled Profile D Profile F Profile
Bottom Drilled and Counterbored 12" Fascia/Side Drilled and Counterbored
on Center and 6" From Each End 12" On Center and 6" From Each End
