SECTION 4 FHC F-SERIES HEAVY-DUTY STAINLESS STEEL POST RAILING SYSTEMS
FHC F-Series Railing Post Components

FHC 1.9" Round Post FHC 1.9" Round Post FHC 1.9" Round Post
Fascia Bracket for Fascia Bracket for Fascia Bracket for Outside 90
Center or End 3-1/2" Inside 90 Degree Corner Degree Corner

4" 4"
- Use With FHC - Use With FHC - Use With FHC
PR19 1.9" O.D. PR19 1.9" O.D. PR19 1.9" O.D.
Pipe Rail Pipe Rail Pipe Rail
- For Center or End - For Inside 90 - For Outside 90
Post Applications Degree Corner Degree Corner
- Pre-Drilled With 6-1/2" Applications 6-1/2" Applications 6-1/2"
(4) 7/16" Diameter - Pre-Drilled - Pre-Drilled
Holes With (4) 7/16" With (4) 7/16"
- 3-1/2" Wide Diameter Holes Diameter Holes
x 6-1/2" Tall
Mounting Base,
3/8" Thick 3/8"
ITEM NO. FINISH ITEM NO. FINISH ITEM NO. FINISH
FB19BS Brushed Stainless FB191BS Brushed Stainless FB190BS Brushed Stainless
FB19PS Polished Stainless FB191PS Polished Stainless FB190PS Polished Stainless
Minimum Order: 1 Each. Minimum Order: 1 Each. Minimum Order: 1 Each.
FHC 2" Square Post FHC 2" Square Post FHC 2" Square Post
Fascia Bracket for Fascia Bracket for Inside Fascia Bracket for Outside
Center or End Post 90 Degree Corner 90 Degree Corner 4"

3-1/2" 4"
- Use With FHC PR20 - Use With FHC - Use With FHC
2" Square Pipe Rail PR20 2" Square PR20 2" Square
- For Center or End Pipe Rail Pipe Rail
Post Applications - For Inside 90 - For Inside 90
- Pre-Drilled With Degree Corner 6-1/2" Degree Corner
(4) 7/16" Diameter 6-1/2" Applications Applications 6-1/2"
Holes - Pre-Drilled - Pre-Drilled
- 3-1/2" Wide X With (4) 7/16" With (4) 7/16"
6-1/2" Tall Mounting Diameter Holes Diameter Holes
Base, 3/8" Thick
3/8"
ITEM NO. FINISH ITEM NO. FINISH ITEM NO. FINISH
FB2BS Brushed Stainless FB21BS Brushed Stainless FB20BS Brushed Stainless
FB2PS Polished Stainless FB21PS Polished Stainless FB20PS Polished Stainless
Minimum Order: 1 Each. Minimum Order: 1 Each. Minimum Order: 1 Each.
FHC 1" X 2" Narrow Rectangular Post Fascia FHC 10-32 Thread Cutting Screw
Brackets for Center or End Post - #10-32 Thread
3/8" 3/4" Long Stainless Steel
- Use With FHC PR12 1"x 2" 3-1/2" - Used to Fasten Brackets
Narrow Rectangular Pipe Rail to Handrail
- For Center or End Post - 100 Screws Per Pack
Applications
- Pre Drilled With (4) 7/16"
Diameter Holes
- 3-1/2" Wide X 6-1/2" Tall 6-1/2"
Mounting Base, 3/8" Thick

ITEM NO. FINISH
FB12BS Brushed Stainless ITEM NO. HB10X32TC
FB12PS Polished Stainless Minimum Order: 1 Pack
Minimum Order: 1 Each.
