SECTION 1 FHC FRAMELESS GLASS RAILINGS
FHC FGR Frameless Glass Railing System Tools

FHC Socket Head FHC Stainless Steel FHC Stainless
Cap Screws Hex Head Screws Steel Washer

- 1/2"-13 Thread Size - M14-20 Thread Size - Flat Washer, Standard for
- 304 Alloy Stainless Steel - 18-8 Stainless Steel General Use
- Works With GRWB1, GRWB2, - Works With GRWB3 Weld Blocks - Various Sizes to Match
and GRWBF1 Weld Blocks - Use With A3M & A5M ACHIEVE Base Shoe Bolt Diameter
®
- Use With ACHIEVE and Traditional Series When Surface Mounting to Steel - 18-8 Stainless Steel
®
Base Shoe When Attaching to Steel - Works With SW14X34 Washer
- 10 Per Pack - 10 Per Pack

ITEM NO. LENGTH ITEM NO. LENGTH
SHS12X34 3/4" Long HXHM14X34 20 mm Long ITEM NO. SIZE QUANTITY
SHS12X1 1" Long HXHM14X1 25 mm Long SW14X34 M14 X 28mm O.D. 10
SHS12X114 1-1/4" Long HXHM14X114 30 mm Long SW38SS 3/8" x 7/8" 100
SHS12X112 1-1/2" Long HXHM14X112 35 mm Long SWM12SS M12 10
Minimum Order: 1 pack. Minimum Order: 1 pack. Minimum Order: 1 pack.

FHC 3/8" Hex Makita ® FHC 3/8" Drive
Bit Socket Impact XPS Socket Extension
- 2-3/4" Overall Length - For use With High Torque - 3" Long
- 3/8" Square Drive Impact Drivers and Driver Drills - 3/8" Square Drive
- Use With 1/2" -13" - 2" long
Socket Head - 3/8" Square Drive
Cap Screws - 1/4" Hex Shank

ITEM NO. 38HBS ITEM NO. XPS38X2SA ITEM NO. 38X3EXT
Minimum Order: 1 Each Minimum Order: 1 Each Minimum Order: 1 Each

FHC Step Drill Bit FHC Deep Sockets
for Drill Press - Six Point
- Available in Two Sizes - Available in Three Sizes
- 3/4" Shank
- Three Fluted
Carbide Tip

ITEM NO. DEPTH LENGTH USE WITH
ITEM NO. DESCRIPTION 916DS 9/16" 2-1/2" Long Use With 3/8" CRC38X4 & HSA38X4
BSD916 9/16" Clear Hole with 7/8" Counter Bore 34DS 3/4" 2-1/2" Long Use With 1/2" CRC12X4 & HSA12X4
BSD1316 13/16" Clear Hole with 1-1/4" Counter Bore 22MMDS 22 mm 2-3/4" Long Use With M14 HXHM14X34 Series
Minimum Order: 1 each. Minimum Order: 1 each.
Makita is a Registered Trademark of Makita Corporation
Visit fhc-usa.com to search for
THE GLAZING SUPPLY COMPANY Railing Tools

46 EXPERIENCE AND INNOV A TION Enter the Item Number or scan QR code with
your smartphone for complete product details
