SECTION 1
SECTION 1 FHC FRAMELESS GLASS RAILINGS
FHC T5M and T5L Traditional Glass Railing Systems

Chat With FHC On Our Website
to Get Real Time Expert Support
from Knowledgeable Reps
Chat With Us!

FHC End Caps for Traditional FHC End Caps for Traditional T5M
Low Profile T5LM Series Base Shoes Series Base Shoes

- Fits T5LM Low Profile - Fits T5M Series Base Shoe
Series Base Shoe 3-9/16" - Install With CT040 High-Bond Tape 4-3/16"
- Install With CT040 High-Bond or S790BL Silicone (See Page 47)
Tape or S790BL Silicone - Custom End Cap Sizes and

(See Page 47) Powder Coat Finishes Available,
- Custom End Cap Sizes and Contact FHC Technical Sales
Powder Coat Finishes Available, for a Quote
Contact FHC Technical Sales - 304 Alloy
for a Quote
- 304 Alloy 2-7/16" END CAP FOR T5M TRADITIONAL BASE SHOE 2-11/16"
ADHESIVE BACK END CAP SCREW IN END CAP
ITEM NO. ITEM NO. FINISH
TS5ECBS T5SECBS Brushed Stainless
ITEM NO. FINISH TS5ECPS T5SECPS Polished Stainless
TL5ECBS Brushed Stainless TS5ECSA T5SECSA Satin Anodized
TL5ECPS Polished Stainless TS5ECMB T5SECMB Matte Black
TL5ECSA Satin Anodized TS5ECDU --- Dark Bronze Anodized
TL5ECMB Matte Black
TS5ECPB --- Polished Brass
Minimum Order: 1 each.
Minimum Order: 1 each.
FHC Traditional Series FHC Traditional 1/4"
One Seal Gasket Spacer Block

- Patent Pending Design Allows for With Adhesive
Outside Gasket to be set Before - Used as a Spacer
Glass is Installed Between Glass Panels 3"
- Same Profile is Used on the - For T5M Series Base Shoe
Inside and Outside of Shoe
- Made From Silicone Coated - 100 Per Box Adhesive
Durable Black EPDM Material
Available in Two Lengths: ITEM NO. ROLL LENGTH
250' and 500' Rolls 1SGM250 250' 15/16"
1SGM500 500' ITEM NO. SBA5
Minimum Order: 1 roll. Minimum Order: 1 Box.
Visit fhc-usa.com to search for
THE GLAZING SUPPLY COMPANY Base Shoes

42 EXPERIENCE AND INNOV A TION Enter the Item Number or scan QR code with
your smartphone for complete product details
