FHC FRAMELESS GLASS RAILINGS SECTION 1
FHC T5M and T5L Traditional Glass Railing Systems

FHC Cladding for T5M Traditional Series FHC Cladding for T5L Traditional
Base Shoe Low Profile Base Shoe
- Designed for use on - Sold Individually in 120" Lengths - Custom Fabrication and Powder Coat
Traditional Series Base Shoes - Installs With CT040 High Bond Tape Services Available Contact FHC Technical
or S790BL Silicone Sales for a Quote

FHC T5M Series FHC T5L Series
End View End View
11/16" 9/16"

4-3/16" 3-9/16"
T5C90 Corner
Cladding For T5M Glass Railing Base
Series Base Shoe ASC10 Base Shoe Sold Separately
TLC10 Base
Shoe Cladding (See Pages 39-40) Shoe Cladding
Sold Each Adhere With CT040 High-Bond Sold Each
Tape or S790BL Silicone Sealant
(See Page 47)
CLADDING FOR T5M SERIES TRADITIONAL BASE
SHOE
ITEM NO. LENGTH FINISH CLADDING FOR T5L SERIES
TRADITIONAL LOW PROFILE BASE SHOE
ASC10BS 120" Long Brushed Stainless 90 DEGREE CORNER CLADDING FOR T5M SERIES TRA DITIONA L L O W PROFILE BASE SHOE
ASC10PS 120" Long Polished Stainless ITEM NO. FINISH ITEM NO. LENGTH FINISH
ASC10SA 120" Long Satin Anodized T5C90BS Brushed Stainless TLC10BS 120" Long Brushed Stainless
ASC10MB 120" Long Matte Black T5C90PS Polished Stainless TLC10PS 120" Long Polished Stainless
ASC10DU 120" Long Dark Bronze Anodized T5C90SA Satin Anodized TLC10SA 120" Long Satin Anodized
ASC10M 120" Long Mill Aluminum T5C90MB Matte Black TLC10MB 120" Long Matte Black
Minimum Order: 1 each. Must Ship Common Carrier. Minimum Order: 1 each. Minimum Order: 1 each. Must Ship Common Carrier.
FHC Fascia Cladding for T5M Traditional Series Base Shoe
- Designed for use on T5M Traditional Series Base Shoes Inside Fascia
- Available in Five Architectural Finishes Cladding Sold Each
- Sold Individually in 120" Lengths
- Installs With CT040 High Bond Tape or S790BL Silicone
- Custom Fabrication and Powder Coat Services Available
Contact FHC Technical Sales for a Quote
5/8" 11/16"

Inside Cladding

4-1/4"

Outside Fascia
Cladding
Outside Cladding Sold Each
2-1/2"
INSIDE CLADDING FOR FASCIA MOUNTED T5M BASE SHOE OUT SIDE CLA DDING FOR F ASCIA MOUNTED T 5 M BASE SHOE
OUTSIDE CLADDING FOR FASCIA MOUNTED T5M BASE SHOE
ITEM NO. LENGTH FINISH ITEM NO. LENGTH FINISH
ASC1FBS 120" Long Brushed Stainless TS50FBS 120" Long Brushed Stainless
ASC1FPS 120" Long Polished Stainless TS50FPS 120" Long Polished Stainless
ASC1FSA 120" Long Satin Anodized TS50FSA 120" Long Satin Anodized
ASC1FMB 120" Long Matte Black TS50FMB 120" Long Matte Black
ASC1FDU 120" Long Dark Bronze Anodized TS50FDU 120" Long Dark Bronze Anodized
Minimum Order: 1 each. Must Ship Common Carrier.
Minimum Order: 1 each. Must Ship Common Carrier.
