FHC FRAMELESS GLASS RAILING CAP RAILS, GASKETS & ACCESSORIES SECTION 2
FHC Stainless Steel Cap Rails

FHC Flat End Caps
for Roll Formed 1/8" FOR 1-1/2" SQUARE CAP RAIL
Square Cap Rails ITEM NO. FINISH
SC15ECBS Brushed Stainless
- 316 Alloy SC15ECPS Polished Stainless
- Adhere With LT32629 Cement Minimum order: 1 each.
and LT7649 Primer (See Page 79) FOR 2" SQUARE CAP RAIL
ITEM NO. FINISH
SC20ECBS Brushed Stainless
SC20ECPS Polished Stainless
Minimum order: 1 each.

FHC Wall Mount End Caps for
Roll Formed Square Cap Rails 1/8" Wall Mount FOR 1-1/2" SQUARE CAP RAIL
- 316 Alloy End Cap ITEM NO. FINISH
Brushed Stainless
SC15WCBS
- Includes 1/4" x 2" Lag Bolt With Grommet SC15WCPS Polished Stainless
- Adhere With LT32629 Cement Minimum order: 1 each.
and LT7649 Primer (See Page 79) Lag Bolt With
Grommet FOR 2" SQUARE CAP RAIL
ITEM NO. FINISH
1/2" Glass SC20WCBS Brushed Stainless
Clearance
Required SC20WCPS Polished Stainless
ITEM NO. WMB0LT1 Minimum order: 1 each.
Mounting Bolt and Spacer
Minimum Order: 1 Each
FHC Square Roll Formed Cap Rail
Connector Sleeves
- For Use With Square Cap Rails
- 5" Long Sleeve Used to Connect and
Align Two Pieces of Cap Rail
- Adhere With LT32629 Cement and
LT7649 Primer (See Page 79)
- Mill Stainless Steel ITEM NO. DESCRIPTION
- 316 Alloy SC15CSS For 1-1/2" Square Cap Rail
SC20CSS For 2" Square Cap Rail
Minimum order: 1 each.

FHC Rubber Gasket for SC15 Cap Rail FHC Rubber Gasket for SC20 Cap Rail
- Securely Attaches Glass to Cap Rail - Securely Attaches Glass to Cap Rail
- 20' Length - 20' Length
- High Quality EPDM Rubber - High Quality EPDM Rubber

15/16" Glass
Deduction
15/16" Glass
Deduction

ITEM NO. DESCRIPTION
ITEM NO. DESCRIPTION CRV3RL For 1/2", 9/16", and 5/8" Glass
CRV6RL For 1/2", 9/16", and 5/16" Glass CRV4RL For 11/16" and 3/4" Glass
CRV7RL For 11/16" and 3/4" Glass CRV5RL For 13/16" Glass
Minimum order: 1 roll. Minimum order: 1 roll.
Visit fhc-usa.com to search for
Cap Rail Accessories FRAMELESS HARDWARE COMPANY LLC
2323 Firestone Blvd. South Gate, CA 90280
Enter the Item Number or scan QR code with Toll Free: (888) 295-4531 | Direct: (323) 968-2031
your smartphone for complete product details 59
Fax: (323) 336-8307 | fhc-usa.com
