SECTION 3 FHC FRAMELESS POINT SUPPORTED RAILING STANDOFF SYSTEMS

FHC Frameless Point

Supported Railing

Standoff Systems

- 2" Diameter or Square Standoff Designs CSI DIVISION 05
- 316 Grade Stainless Steel for Interior and SECTION
Exterior Applications 05 7300
- For 1/2" to 13/16" Thick Tempered Glass
- Three Architectural Finishes Available
- Can be Custom Manufactured to
Meet Your Specifications
FHC Frameless Point Supported Glass Railing Standoff Systems
offer a modern aesthetic, and are architecturally desirable to
designers and property owners for a wide variety of applications.
Our point-supported glass railing systems side mount to a
balcony/stair case using either a steel back plate or, for a
minimalist design, the standoff body. They are designed to hold
1/2" to 13/16" thick tempered or laminated glass panels, to give
the appearance of floating glass. Made from 316 stainless steel, For more information about our Frameless Point Supported
our Frameless Point Supported Railing Standoffs are intended Glass Railing Standoff Systems, or to get a quote for your project,
for both interior and exterior applications offering a clean, contact our Business Development Team at (888) 295-4531 or
contemporary high-end look with unobstructed views and added via email at railings@fhc-usa.com. We look forward to assisting
safety, while holding up against the elements. you with your railing design.

Typical Railing Standoff Layout

60" Recommended Maximum See SECTION 2
Glass Panel Width (Pages 49-80) for Top Rail
options

See SECTION 5
(Pages 109-128) for Handrail
options

42"
Overall
Height
Varies Line of Finished Floor

C L C L C L
6" Equal Equal 6"

4" Minimum
1.5" Minimum

Visit fhc-usa.com to search for
THE GLAZING SUPPLY COMPANY Standoffs

82 EXPERIENCE AND INNOV A TION Enter the Item Number or scan QR code with
your smartphone for complete product details
