SECTION 4 FHC F-SERIES HEAVY-DUTY STAINLESS STEEL POST RAILING SYSTEMS

FHC F1 Series Railing Post Components

FHC Replacement Saddles - Designed to be Used With Fixed and - Radius Saddles Compatible With 1-1/2" to 2"
Swivel Stems Round Top Rail
for F1 Series Railing Post - 90, 135, and 180 Degree Radius and - Available In Two Architectural Finishes
Flat Saddles - Includes (2) #10-32 Handrail Mounting Screws
- 316 Grade Stainless Steel
FHC Radius Saddles for Round Tubing
FHC RADIUS SADDLES
ITEM NO. ANGLE FINISH
PS1BS 180 Degree Brushed Stainless
PS1PS 180 Degree Polished Stainless
PS9BS 90 Degree Brushed Stainless
3" 3" 3" PS9PS 90 Degree Polished Stainless
3" 3" PS3BS 135 Degree Brushed Stainless
PS3PS 135 Degree Polished Stainless
MODEL PS1 MODEL PS9 MODEL PS3 Minimum Order: 1 Each.
180 Degree Saddle 90 Degree Saddle 135 Degree Saddle
FHC Flat Saddles for Square or Rectangular Tubing

FHC FLAT SADDLES
ITEM NO. ANGLE FINISH
PF1BS 180 Degree Brushed Stainless
PF1PS 180 Degree Polished Stainless
3" 3" 3" 3" 3" PF9BS 90 Degree Brushed Stainless
PF9PS 90 Degree Polished Stainless
PF3BS 135 Degree Brushed Stainless
PF3PS 135 Degree Polished Stainless
MODEL PF1 MODEL PF9 MODEL PF3
180 Degree Saddle 90 Degree Saddle 135 Degree Saddle Minimum Order: 1 Each.
FHC 1.9" Round Post FHC 1.9" Round Post FHC 1.9" Round Post
Fascia Bracket for Fascia Bracket for Fascia Bracket for
Center or End Inside 90 Degree Corner Outside 90 Degree Corner
- Use With FHC PR19 1.9" O.D. Pipe Rail - Use With FHC PR19 1.9" O.D. Pipe Rail - Use With FHC PR19 1.9" O.D. Pipe Rail
- For Center or End Post Applications - For Inside 90 Degree Corner Applications - For Outside 90 Degree Corner Applications
- Pre-Drilled With (4) 7/16" Diameter Holes - Pre-Drilled With (4) 7/16" Diameter Holes - Pre-Drilled With (4) 7/16" Diameter Holes
- 3-1/2" Wide x 6-1/2" Tall Mounting Base, - Available in Two Architectural Finishes - Available in Two Architectural Finishes
3/8" Thick
- Available in Two Architectural Finishes
4"
4"
3-1/2"

6-1/2"
6-1/2" 6-1/2"

3/8"

ITEM NO. FINISH ITEM NO. FINISH ITEM NO. FINISH
FB19BS Brushed Stainless FB191BS Brushed Stainless FB190BS Brushed Stainless
FB19PS Polished Stainless FB191PS Polished Stainless FB190PS Polished Stainless
Minimum Order: 1 Each. Minimum Order: 1 Each. Minimum Order: 1 Each.
visit fhc-usa.com to search for
Railing Posts
THE GLAZING SUPPLY COMPANY
Enter the Item Number or scan QR code with
68 EXPERIENCE AND INNOV A TION your smartphone for complete product details
