SECTION 4 FHC F-SERIES HEAVY-DUTY STAINLESS STEEL POST RAILING SYSTEMS

FHC F-Series Top Rails and Components

FHC 1-1/2" O.D. Heavy-Duty Tubing
.120" Wall
- 1-1/2" Outside Diameter - End Caps, Corners, Sleeves Thickness
With .120" Wall Thickness and Post Components Sold
- 240" Lengths Separately
- Available In Two - Custom Fabrication Services
Architectural Finishes Available. Contact FHC
Technical Sales for a Quote
- 304 Grade Stainless Steel

ITEM NO. Length FINISH
THD15BS 240" Brushed Stainless
THD15PS 240" Polished Stainless Ø1-1/2"
Minimum Order: 1 Each. Must Ship Common Carrier.

FHC Horizontal 90 Degree Corner for
1-1/2" O.D. Heavy-Duty Tubing
6" 6"
- For Heavy-Duty 1-1/2" Diameter Tubing
With .120" Wall Thickness
- Install With (2) THD15CSS Connector Sleeves
(Sold Separately)
- Adhere With LT32629 Cement and ITEM NO. FINISH
LT7649 Primer (See Page 82) THD15HBS Brushed Stainless
- Custom Fabrication Services Available. 90° THD15HPS Polished Stainless
Contact FHC Technical Sales for a Quote
Minimum Order: 1 Each.
- 304 Grade Stainless Steel

FHC Horizontal 135 Degree Corner for
1-1/2" O.D. Heavy-Duty Tubing
6" 6"
- For Heavy-Duty 1-1/2" Diameter Tubing
With .120" Wall Thickness
- Install With (2) THD15CSS Connector Sleeves
(Sold Separately)
- Adhere With LT32629 Cement and ITEM NO. FINISH
LT7649 Primer (See Page 82)
THD15H3BS Brushed Stainless
- Custom Fabrication Services Available. 135° THD15H3PS Polished Stainless
Contact FHC Technical Sales for a Quote
Minimum Order: 1 Each.

FHC Vertical 147 Degree Corner for 147°
1-1/2" O.D. Heavy-Duty Tubing

- For Heavy-Duty 1-1/2" Diameter Tubing
With .120" Wall Thickness
- Install With (2) THD15CSS Connector Sleeves 6"
(Sold Separately)
ITEM NO. FINISH
- Adhere With LT32629 Cement and 6" THD15H7BS Brushed Stainless
LT7649 Primer (See Page 82) THD15H7PS Polished Stainless
- Custom Fabrication Services Available. Minimum Order: 1 Each.
Contact FHC Technical Sales for a Quote
FHC End Caps for 1-1/2" O.D. FHC Connector Sleeves for
Heavy-Duty Tubing 1-1/2" O.D. Heavy-Duty Tubing
- End Caps for THD15 Pipe Rail - 5" Long Internal Connector for THD15
- 304 Grade Stainless Steel - Used To Connect Two Straight Pieces
- Install Using LT32629 Cement and of Rail or Corner Connections
LT7649 Primer (See Page 82) - 304 Grade Stainless Steel
- Install Using
LT32629 Cement
ITEM NO. FINISH and LT7649 Primer
THD15ECBS Brushed Stainless ITEM NO. THD15CSS
THD15ECPS Polished Stainless Minimum Order 1 Each
Minimum Order: 1 Each.
visit fhc-usa.com to search for
Railing Posts
