SECTION 4 FHC F-SERIES HEAVY-DUTY STAINLESS STEEL POST RAILING SYSTEMS

FHC F-Series Top Rails and Components

FHC 1.9" O.D. Pipe Rail .145" Wall
Thickness
- 1.9" Outside Diameter - Custom Fabrication Services
- 240" Length Available. Contact FHC
Technical Sales for a Quote
- Available In Two
Architectural Finishes - 304 Grade Stainless Steel
- End Caps, Corners, Sleeves and
Post Components Sold Separately
ITEM NO. Length FINISH
PR19BS 240" Brushed Stainless
Ø1.9"
PR19PS 240" Polished Stainless
Minimum Order: 1 Each.
Must Ship Common Carrier.
FHC Horizontal 90 Degree Corner for
1.9" O.D. Pipe Rail
6" 6"
- Install with (2) PR19CS Connector Sleeves
(Sold Separately) (See Page 82)
- Adhere with LT32629 Cement and
LT7649 Primer (See Page 82)
- Custom Fabrication Services Available. ITEM NO. FINISH
Contact FHC Technical Sales for a Quote PR19HBS Brushed Stainless
- 304 Grade Stainless Steel 90° PR19HPS Polished Stainless
Minimum Order: 1 Each.

FHC Horizontal 135 Degree Corner for
1.9" O.D. Pipe Rail
6" 6"
- Install with (2) PR19CS Connector Sleeves
(Sold Separately)
- Adhere with LT32629 Cement and
LT7649 Primer (See Page 82) ITEM NO. FINISH
- Custom Fabrication Services Available. PR19H3BS Brushed Stainless
Contact FHC Technical Sales for a Quote PR19H3PS Polished Stainless
- 304 Grade Stainless Steel 135° Minimum Order: 1 Each.

FHC Vertical 147 Degree Corner for
147°
1.9" O.D. Pipe Rail
- Install with (2) PR19CS Connector Sleeves
(Sold Separately)
- Adhere with LT32629 Cement and
LT7649 Primer (See Page 82) ITEM NO. FINISH
6" PR19VBS Brushed Stainless
- Custom Fabrication Services Available.
Contact FHC Technical Sales for a quote 6" PR19VPS Polished Stainless
Minimum Order: 1 Each.
- 304 Grade Stainless Steel
FHC End Cap for FHC Connector Sleeves for
1.9" O.D. Pipe Rail 1.9" O.D. Pipe Rail
- For PR19 1.9" O.D. Pipe Rail - Internal Connector for 1.9" O.D. Pipe Rail
- 316 Grade Stainless Steel - Used To Connect Two Straight Pieces of
- Install Using LT32629 Cement Rail or Corner Connections
and LT7649 Primer - Mill Stainless Steel
(See Page 82) - 316 Grade Stainless Steel

- Install Using LT32629
Cement and LT7649
Primer (See Page 82)
ITEM NO. FINISH
PR19ECBS Brushed Stainless
PR19ECPS Polished Stainless
ITEM NO. PR19CS
Minimum Order: 1 Each.
Minimum Order 1 Each
visit fhc-usa.com to search for
Pipe Rails
