SECTION 4 FHC F-SERIES HEAVY-DUTY STAINLESS STEEL POST RAILING SYSTEMS
FHC F-Series Top Rails and Components

FHC 1-1/2" O.D. Heavy-Duty Tubing
- 1-1/2" Outside Diameter - End Caps, Corners, Sleeves .120" Wall
Thickness
With .120" Wall Thickness and Post Components Sold
- 240" Lengths Separately
- Available in Two - Custom Fabrication Services
Architectural Finishes Available. Contact FHC
- 304 Grade Stainless Steel Technical Sales for a Quote

ITEM NO. Length FINISH
THD15BS 240" Brushed Stainless
THD15PS 240" Polished Stainless Ø1-1/2"
Minimum Order: 1 Each. Must Ship Common Carrier.
FHC Horizontal 90 Degree Corner for
1-1/2" O.D. Heavy-Duty Tubing
- For Heavy-Duty 1-1/2" Diameter Tubing 6" 6"
With .120" Wall Thickness
- Install With (2) THD15CSS Connector Sleeves
(Sold Separately)
- Adhere With LT32629 Cement and
LT7649 Primer (See Page 99) 90° ITEM NO. FINISH
- Custom Fabrication Services Available. THD15HBS Brushed Stainless
Contact FHC Technical Sales for a Quote THD15HPS Polished Stainless
- 304 Grade Stainless Steel Minimum Order: 1 Each.
FHC Horizontal 135 Degree Corner for
1-1/2" O.D. Heavy-Duty Tubing 6" 6"
- For Heavy-Duty 1-1/2" Diameter Tubing
With .120" Wall Thickness
- Install With (2) THD15CSS Connector Sleeves
(Sold Separately)
- Adhere With LT32629 Cement and ITEM NO. FINISH
LT7649 Primer (See Page 99) 135° THD15H3BS Brushed Stainless
- Custom Fabrication Services Available. THD15H3PS Polished Stainless
Contact FHC Technical Sales for a Quote Minimum Order: 1 Each.

FHC Vertical 147 Degree Corner for 147°
1-1/2" O.D. Heavy-Duty Tubing
- For Heavy-Duty 1-1/2" Diameter Tubing
With .120" Wall Thickness
- Install With (2) THD15CSS Connector Sleeves 6"
(Sold Separately)
- Adhere With LT32629 Cement and 6" ITEM NO. FINISH
LT7649 Primer (See Page 99) THD15H7BS Brushed Stainless
- Custom Fabrication Services Available. THD15H7PS Polished Stainless
Minimum Order: 1 Each.
Contact FHC Technical Sales for a Quote
FHC End Caps for 1-1/2" O.D. FHC Connector Sleeves for
Heavy-Duty Tubing 1-1/2" O.D. Heavy-Duty Tubing

- End Caps for THD15 Pipe Rail - 5" Long Internal Connector for THD15
- 304 Grade Stainless Steel - 304 Grade Stainless Steel
- Install Using LT32629 Cement and - Install Using
LT7649 Primer (See Page 99) LT32629 Cement
ITEM NO. FINISH and LT7649 Primer
THD15ECBS Brushed Stainless - Used to Connect Two Straight Pieces
THD15ECPS Polished Stainless of Rail or Corner Connections ITEM NO. THD15CSS
Minimum Order: 1 Each. Minimum Order: 1 Each
