FHC F-SERIES HEAVY-DUTY STAINLESS STEEL POST RAILING SYSTEMS SECTION 4
FHC F-Series Top Rails and Components

FHC 2" Square Pipe Rail 240" Lengths

- 2" x 2" Square Profile - End Caps, Corners, Sleeves
- 3/16" Wall Thickness and Post Components Sold 3/16" Wall
Thickness
Separately
- 240" Lengths - Custom Fabrication Services
- Available in Two Available. Contact FHC 2"
Architectural Finishess Technical Sales for a Quote
- 304 Grade Stainless Steel
ITEM NO. Lengths FINISHES
PR20BS 240" Brushed Stainless
PR20PS 240" Polished Stainless 2"
Minimum Order: 1 Each.
Must Ship Common Carrier.
FHC 90° Degree Corner
for 2" Square Pipe Rail - Adhere With LT32629 Cement and

- 6" x 6" Outside Dimension 6" 6" LT7649 Primer (See Page 99).
- 90 Degree Corner - Custom Fabrication Services
Available. Contact FHC Technical
- 304 Grade Stainless Steel Sales for a Quote
- For PR20BS 2" x 2" Square Rail
With 3/16" Wall Thickness ITEM NO. FINISH
- Install with (2) PR20CS PR20HBS Brushed Stainless
Connector Sleeves 90° PR20HPS Polished Stainless
(Sold Separately) Minimum Order: 1 Each.
FHC 135° Degree Corner
for 2" Square Pipe Rail 6" 6" - Adhere With LT32629 Cement and
- 6" x 6" Outside Dimension LT7649 Primer (See Page 99).
- 135 Degree Corner - Custom Fabrication Services
- 304 Grade Stainless Steel Available. Contact FHC Technical
Sales for a Quote
- For PR20BS 2" x 2" Square Rail
With 3/16" Wall Thickness
- Install with (2) PR20CS ITEM NO. FINISH
Connector Sleeves 135° PR20H3BS Brushed Stainless
(Sold Separately) PR20H3PS Polished Stainless
Minimum Order: 1 Each.
FHC Vertical 147° Degree Corner - Adhere With LT32629 Cement and
for 2" Square Pipe Rail LT7649 Primer (See Page 99).

- 6" x 6" Outside Dimension 147° - Custom Fabrication Services
Available. Contact FHC Technical
- 147 Degree Corner Sales for a Quote
- For PR20BS 2" x 2" Square Rail
With 3/16" Wall Thickness 6"
- 304 Grade Stainless Steel ITEM NO. FINISH
Brushed Stainless
PR20VBS
- Install with (2) PR20CS PR20VPS Polished Stainless
Connector Sleeves (Sold Separately) 6" Minimum Order: 1 Each.
FHC End Caps for 2" FHC Connector Sleeves for
Square Pipe Rail 2" Square Pipe Rail
- For PR20BS 2" x 2" Square Rail - For PR20BS 2" x 2" Square Rail
With 3/16" Wall Thickness With 3/16" Wall Thickness
- Adhere With LT32629 Cement and - Mill Stainless Steel
LT7649 Primer (See Page 99) - Adhere With
- Custom Angles and Fittings Available. LT32629 Cement
Contact FHC Technical Sales for and LT7649 Primer
More Information ITEM NO. FINISH (See Page 99)
- Flat End Cap PR20ECBS Brushed Stainless - 5 Long Internal Connector
PR20ECPS Polished Stainless ITEM NO. PR20CS
Minimum Order: 1 Each. Minimum Order: 1 Each
