SECTION 1 FHC FRAMELESS GLASS RAILINGS
FHC ACHIEVE FGR Frameless Glass Railing System
®
FHC ACHIEVE Installation &
®
Removal Tool Kit Everything You Need

to Install or Remove
- Extremely Simple and Easy to Use FHC ACHIEVE Shims
®
- Designed for use With FHC’s Revolutionary is Included in This Kit.
ACHIEVE Shim Sets
®
- FHC’s ACHIEVE Tool Kit Includes Everything Needed
®
for the Installation and Removal Process
- Quality Heavy-Duty Stainless Steel Tools, Built to Last
- FHC’s Precision Engineered Tool Design Allows for
Accurately Measured Installs Every Time
- Works With Monolithic and Laminated SGP Tempered Glass
- For Use With Surface Mount, Fascia/Side Mount,
and Recessed Mount Base Shoe Applications
- No More Messy Wet Set Cement
- US Patent Nos. 11,686,102 B2 and 11,613,895 B2

Typical Shim and Anchor Spacing

ITEM NO. ACH1K
Minimum Order: 1 Each.
12" - 14" ACHIEVE ®
Shim Spacing
6" KIT INCLUDES:
- Tool Bag - Two Glass Staging
- Installation Tool Pads
- Removal Tool - Vinyl Roller
- Glass Setting Tool
- 2 Lb. Deadblow
C L C L 12" Typical Hammer
Anchor Spacing

Heavy-Duty Heavy-Duty Glass Setting 2LB. Dead-Blow Glass Staging Vinyl Roller
Stainless Steel Stainless Steel Tool Hammer Pads Tool
Installation Tool Removal Tool

Fast & Easy Installation
1 2 3 ICC
Install Base Shoe,
1 Exterior Gasket &
Setting Block
ESR-4814
2 Install Glass & Set Shims
Using Installation Tool

Apply Cladding &
3 Roll-In Interior Gasket Using
VRT17 Vinyl Roller Tool to
Finish the Install
