FHC FRAMELESS GLASS RAILINGS SECTION 1
FHC ACHIEVE FGR Frameless Glass Railing System
®
FHC ACHIEVE
®
Dry Glaze Shim Sets

- No More Messy Wet Set Cement
- Shim Sets for 1/2" to 3/4" and
13/16" to 1-1/16" Glass U.S. Patent No. 11,686,102 B2
- Packaged 10 Shim Sets Per Box
- Works With FHC ACHIEVE Series
®
Base Shoes
- Can be Used With Surface Mount, ICC
Fascia/Side Mount, and Recessed
Mount Base Shoe Applications
- Designed for Use With FHC
Item No. ACH1K Installation Tool
ACHIEVE ® SHIMS ESR-4814
ITEM NO. DESCRIPTION
ACH2G For 1/2" to 3/4" Glass
ACH3G For 13/16" to 1-1/16" Glass 10 Shim Sets Per Box
Minimum Order: 1 box.
Fast & Easy
Install ACHIEVE Shims Every
®
12" to 14" on Center Installation

NEW
INNOVATIVE
DESIGN

ACHIEVE Shim
®
Installation
FHC ACHIEVE Setting Block Spacing
®
4" - 7" 12" - 14"

C L C L

ACHIEVE ® SHIM AND SETTING BLOCK SPACING
MINIMUM NO.
OF SHIM SETS GLASS LITE WIDTH
1 Shim Set Less Than 14"
2 Shim Sets 14" to 28" Wide
3 Shim Sets 28" to 42" Wide
4 Shim Sets 42" to 56" Wide
5 Shim Sets 56" to 70" Wide
6 Shim Sets 70" to 84" Wide ACHIEVE
®
®
7 Shim Sets 84" to 96" Wide ACHIEVE Shim
Setting Block Removal
