SECTION 1
SECTION 1 FHC FRAMELESS GLASS RAILINGS
FHC ACHIEVE FGR Frameless Glass Railing System
®
FHC Base Shoe Quick Reference Guide

®
BASE SHOE GLASS ACHIEVE ONE SEAL WELD DRAIN WOOD MOUNT STEEL CONCRETE
ATTACHMENT
ANGLE
SIZE
ATTACHMENT
BLOCKS
GASKET
SHIMS
BLOCKS
GRWB2 GRDB2
Surface Surface
1/2" to 9/16" ACH2G 1SGA500 Mount Mount GRWA1 1/2" - 13 CRC38X4
1SGA250 GRWBF1 GRDBF1 SHS12X34
A1M SERIES Fascia Fascia
ACHIEVE Mount Mount
®
(See Page 31)
GRWB3 GRDB3
Surface Surface
M14-2.0
11/16" ACH2G 1SGA500 Mount Mount GRWA2 HXHM14X34 CRC12X4
1SGA250 GRWBF1 GRDBF1
A3M SERIES Fascia Fascia & SW14X34
ACHIEVE Mount Mount
®
(See Page 32)
GRWB3 GRDB3
Surface Surface
M14-2.0
13/16" ACH3G 1SGA500 Mount Mount GRWA2 HXHM14X34 CRC12X4
1SGA250 GRWBF1 GRDBF1
A5M SERIES Fascia Fascia & SW14X34
®
ACHIEVE Mount Mount
(See Page 33)
GRWB3 GRDB3
Surface Surface
M14-2.0
1-1/16" ACH3G 1SGA500 Mount Mount GRWA2 HXHM14X34 CRC12X4
1SGA250 GRWBF1 GRDBF1
A6M SERIES Fascia Fascia & SW14X34
ACHIEVE Mount Mount
®
(See Page 34)
Not GRWB1 GRDB1
1/2" to 9/16" Applicable 1SGM500 Surface Surface GRWA1 1/2" - 13 CRC38X4
Wet Glaze 1SGM250 SHS12X34
Only Mount Mount
T5L SERIES
(See Page 38)
GRDB1
Surface
Not GRWB1 Mount
1/2" to 9/16" Applicable 1SGM500 Surface GRWA1 1/2" - 13 CRC38X4
Wet Glaze 1SGM250 SHS12X34
Only Mount GRDBF1
T5M SERIES Fascia
(See Page 40) Mount
FHC ACHIEVE and Traditional
®
Base Shoe Sample Kits
- 12" Long Section of Shoe
- Includes ACHIEVE Shims, Gasket and Four Standard Great for
®
Cladding Finishes; Brushed Stainless, Polished Stainless, Project Submittals
Satin Anodized, and Matte Black
12" BASE SHOE SAMPLE KITS
ITEM NO. DESCRIPTION
A1MSK A1M ACHIEVE ® Series Base Shoe Sample Kit Glass Not
A3MSK A3M ACHIEVE ® Series Base Shoe Sample Kit Included
A5MSK A5M ACHIEVE ® Series Base Shoe Sample Kit
A6MSK A6M ACHIEVE ® Series Base Shoe Sample Kit
T5M Traditional Series Base Shoe Sample Kit
T5MSK (Does Not Include ACHIEVE Shims) Each Kit Includes
®
T5M Traditional Low Profile Series Base Shoe Sample Kit
T5LMSK (Does Not Include ACHIEVE ® Shims) Four Different
Minimum Order: 1 each. Cladding Finishes
Visit fhc-usa.com to search for
THE GLAZING SUPPLY COMPANY Base Shoe
30 EXPERIENCE AND INNOV A TION Enter the Item Number or scan QR code with
your smartphone for complete product details
