SECTION 1 FHC FRAMELESS GLASS RAILINGS
SECTION 1
FHC ACHIEVE FGR Frameless Glass Railing System
®

Supports 11/16"
Laminated Tempered
Glass 5/16" x .060 x 5/16"
FHC’s Innovative Patented
“One Seal” 1SGA Dual FHC A3M
Purpose Gasket. Now you
can Pre-Load or Roll in the
Same Gasket Series
(See Page 36)
11/16"
Glass Railing Base Shoe
Designed for use With FHC’s - New Innovative Design Maintains Railing
US Patented ACHIEVE Dry Industry Standard 4-1/8" Base Shoe Height
®
Glaze Shim Set Technology

ITEM NO. A1C90MB (See Page 29) - Compatible With 11/16" Tempered Laminated
For Cladding Options Glass Thickness Range: .665" Min to .726" Max
(See Page 35) - New Design - 40% Lighter Than

Heavy-Duty Vertical Wall Traditional Base Shoes
Design for Taller Custom
Windscreen Applications - 10' and 20' Stock Lengths Drilled or Undrilled
ICC - Designed for Heavy Glass Railing and

FHC’s Tested and Windscreen Applications
Engineered Profile is 40%
Lighter Than Traditional - Custom Fabrication Services Available
Base Shoes - 6063-T5 Aluminum Alloy
ESR-4814 Field Drilling Base Shoe - FHC’s Innovative “One Seal” 1SGA Series Gasket
Just got Easier With our Makes Installations Easy. Installers can Pre-Load
Engineered Hollow Profile Gasket Before Setting Glass and use the Same
Design on all Base Shoe Gasket on the Inside to Finish Installation
Profiles - US Patent Nos. 11,686,102 B2 and 11,613, 895 B2
A3M ACHIEVE ® SERIES ALUMINUM BASE SHOE
ITEM NO. DESCRIPTION
A3M10 Undrilled 120" Long
A3M10D Bottom Drilled 12" C.T.C. 120" Long
A3M10D6 Bottom Drilled 6 " C.T.C. 120" Long
A3M10F Fascia Drilled 12" C.T.C. 120" Long
A3M10F6 Fascia Drilled 6" C.T.C. 120" Long
A3M20 Undrilled 240" Long
A3M20D Bottom Drilled 12" C.T.C. 240" Long ITEM NO. ACH2G ITEM NO. ACH1K
A3M20D6 Bottom Drilled 6" C.T.C. 240" Long FHC ACHIEVE Glass Rail Shim Set ACHIEVE Installation
®
®
A3M20F Fascia Drilled 12" C.T.C. 240" Long 10 Shim Sets Per Box Tool Kit
A3M20F6 Fascia Drilled 6" C.T.C. 240" Long
Minimum Order: 1 each. Must Ship Common Carrier.
1-1/2" 1-1/2" 1-1/2"

4-1/8"

4-1/8" 4-1/8" 7/8"

1-1/4" 9/16"
13/16" 13/16"
13/16"
13/16"
3" 3" 3"
Undrilled Profile D Profile F Profile
Bottom Drilled and Counterbored Fascia/Side Drilled and Counterbored
12" on Center and 6" From Each End 12" On Center and 6" From Each End
or 6" on Center and 3" From Each End or 6" on Center and 3" From Each End
ICC-ES is a registered trademark of ICC Evaluation Service LLC.
Visit fhc-usa.com to search for
THE GLAZING SUPPLY COMPANY Base Shoe

32 EXPERIENCE AND INNOV A TION Enter the Item Number or scan QR code with
your smartphone for complete product details
