Page 73 - FGR26-Frameless-Glass-Railing

FHC FRAMELESS GLASS RAILING CAP RAILS, GASKETS & ACCESSORIES SECTION 2
FHC Aluminum Cap Rails

FHC Flat End Caps
for 1-7/8" Diameter Cap Rail 1/8"
- Available in Two
Architectural Finishes,
Plus Mill Aluminum
- Adhere With LT32629 Cement
and LT7649 Primer
(See Page 79)

FOR 1-7/8" ALUMINUM CAP RAIL
ITEM NO. FINISH
CR19ECSA Satin Anodized
CR19ECMB Matte Black
CR19ECM Mill Aluminum
Minimum order: 1 each.

FHC Wall Mount End Caps 1/8" Wall Mount
End Cap
for 1-7/8" Diameter Cap Rail

- Includes 1/4" x 2" Lag Bolt
With Nylon Grommet Lag Bolt With
- Adhere With LT32629 Cement Grommet
and LT7649 Primer (See Page 79) 1/2" Glass
- Custom Fabrication Available, Clearance
Contact FHC Technical Sales for Required
More Information
FOR 1-7/8" ALUMINUM CAP RAIL
ITEM NO. FINISH
ITEM NO. WMB0LT1 CR19WCSA Satin Anodized
Mounting Bolt and Spacer CR19WCMB Matte Black
Minimum Order: 1 Each CR19WCM Mill Aluminum
Minimum order: 1 each.

FHC 1-7/8" Diameter Aluminum
Cap Rail Connector Sleeves
- 5" Long Internal Connector
Used to Align Cap Rails
- Used With CR19
Aluminum Cap Rail
- Adhere With LT32629 Cement
and LT7649 Primer (See Page 79)

ITEM NO. DESCRIPTION
CR19CSM For 1-7/8" Aluminum Cap Rail
Minimum order: 1 each.

FHC Rubber Gasket for CR19 Aluminum Cap Rail
- Securely Attaches Glass to Cap Rail
- 20' Length
Glass
- High Quality EPDM Rubber 5/8" Deduction
ITEM NO. DESCRIPTION
CRV3RL For 1/2" and 9/16" Glass
CRV4RL For 11/16" and 3/4" Glass
CRV5RL For 13/16" Glass
Minimum order: 1 roll.
