SECTION 5 FHC HANDRAILS, BRACKETS, & COMPONENTS
FHC Handrail Components

FHC Stainless Steel FHC Stainless Steel
12"
Flange, Stanchion, Internal Flange Cover
Post
and Cover Stanchion - Cover Plate Only
- 12" Tall Internal Steel Stanchion - 4-3/16" Diameter
With Floor Mount Plate - For Use With
- For Use With THR15 1-1/2" 1-1/2" Outside
Diameter Tubing with .050" Diameter Tubing
Wall Thickness
- Includes Stainless Steel 12" 1"
Cover Plate Tall
- Use Item No. LT32629 Metal Cover
Plate
Contact Cement and Item No.
LT7649 Primer for Attachment
(See Page 98) Base
Flange 4-3/16"
ITEM NO. FINISH ITEM NO. FINISH
THR15XBS Brushed Stainless THR15XCBS Brushed Stainless
THR15XPS Polished Stainless THR15XCPS Polished Stainless
3-1/2"
Minimum Order: 1 Each. Minimum Order: 1 Each.
Base
FHC Stainless Steel Set FHC Concealed Mounting Base
Full Flange Screw - Use with 1-1/2" Diameter
Stainless Tubing FHC 1-7/16"
- For Use with THR15 1-1/2" Item No. THR15 for
Outside Diameter Tubing Concealed Mounting
- Used for Wall or Floor Mount - Mill Stainless Steel
Installations - Drilled & Tapped 5/16"-18
- Includes (3) #12 Flat Head (One Side Only)
Mounting Screws - Use Item No. LT32629 3"
Metal Contact Cement and
Item No. LT7649 Primer
for Attachment
(See Page 98)
2-15/16"

ITEM NO. FINISH
THR15YBS Brushed Stainless Item No. THR15CMB
THR15YPS Polished Stainless Minimum Order: 1 Each
Minimum Order: 1 Each.
FHC Stainless Steel FHC Stainless Steel FHC Connector Sleeves
Floor Socket Straight Saddle - Use with 1-1/2" Diameter
With Cap - 1-1/2" Stainless Tubing FHC Item
No. THR15
Removable Cap
Diameter 2-13/16" - 5" long Internal Connector
- Use with 1-1/2" 3-11/16" Handrail - Mill Stainless Steel
Diameter Fittings - Use Item No. LT32629
Handrail Fittings - For Use With Metal Contact Cement and
- Floor Socket THR15 1-1/2" Item No. LT7649 Primer
With Removable Diameter for Attachment
Cap Handrail .050" (See Page 98)
- For Use With 3-5/8" Wall Thickness 2"
1-1/2" Outside - Top Saddle
Diameter Tubing Accepts 1-1/2"
Diameter O.D.
Tubing

ITEM NO. FINISH ITEM NO. FINISH
THR15FSBS Brushed Stainless THR15VBS Brushed Stainless
THR15FSPS Polished Stainless THR15VPS Polished Stainless Item No. THR15CSS
Minimum Order: 1 Each. Minimum Order: 1 Each. Minimum Order: 1 Each
