FHC Aluminum Sunshades
®
FHC Aluminum ®

Sunshades

- Structurally Designed to Meet Load Values
- Standard 4", 6" and 8" Brackets,
Outriggers and Fascias
- Available in Anodized, Powder Coat
®
and Kynar Paint Finishes
- Prefabricated Outriggers and Mounting
Brackets for Quick Turnaround Times
- Can Be Customized to Meet Project Requirements,
Contact FHC Technical Sales for More Information

Typical Sunshade Detail
Airfoil Model Shown
Fascia

Airfoil Blade Outrigger
FHC Sunshade Configurations

STEP 1: Mounting Bracket Options (Specify) STEP 3: Blade Options (Specify)

ITEM NO. ASBTXX ITEM NO. ASBLXX ITEM NO.
Wall Mount Wall Mount ASCWBXX "Z" Airfoil Rectangular
Center Bracket End Bracket Curtain Wall Blade Model Blade Model Blade Model
Bracket

STEP 2: Outrigger Options (Specify) STEP 4: Fascia Options (Specify)

ITEM NO. ITEM NO. ITEM NO.
A1X4RBXX A1X6RBXX A2X8RBXX
Square Custom 1" x 4" 1" x 6" 2" x 8"
Standard
Available Finishes

XX Denotes Finish

A PT KN
ANODIZED CUSTOM CUSTOM DESIGNED & MANUFACTURED BY
PAINTED KYNAR FRAMELESS HARDWARE COMPANY
FINISH
