FHC GLASS GATE SYSTEMS AND HARDWARE SECTION 7
FHC Glass Gate Door Rails

Top
HERC-DOOR ®
Monolithic Tempered
Patch Fittings
or Laminated Glass
(See Pages 116-117)
Each FHC Door Rail U.S. Patent No. 11,060,341
is Factory Designed Dual-Inclined Bearing
to Allow for Vertical Surface Controls
Adjustment of Plus Angularity and Self
1/16" or Minus 1/16" Centering of the Rail
With Our Included Door U.S. Patent No. 11,187,323
Rail Setting Blocks. Unitizing Clamping Gasket
Solid One Piece
Rail Housing Cladding Included on Stainless
Steel and Brass Finishes
2-1/2"
2-1/4" Overall Deduction
1-7/8" Glass Deduction
(Includes 3/8" Standard
Clearance)
3/8" Clearance
Standard
FHC Low Profile
Rails are Factory
Prepped Directly
to Door Rail
Elevation
Tapered
®
Profile Shown 60 Degree Bottom HERC-DOOR Rails
A.D.A Compliant
Tapered Top Edge

New Innovative Built-In
Anti-Clamshell Pad

Prevents Chipped Glass
Corners During Installation
U.S. Patent Nos. 11,060,341 and 11,187,323
2-1/2" Low Profile Tapered Door Rail for 5/8", 3/4", 11/16" or 13/16" Tempered or Laminated Glass

PRODUCT INFO/SPECIFICATIONS:
Chat With FHC On Our Website
to Get Real Time Expert Support
- CSI Format Specifications are Available for Download at fhc-usa.com
- End Caps are Included with Every Door Rail from Knowledgeable Reps
- Door Rails With Locks are Supplied Prepped and Installed, Keyed Cylinders, and
Thumbturns are Sold Separately
- FHC Follows GANA Guidelines for Maximum Door Height and Widths. Chat With Us!
®
Reference the FHC HERC-DOOR Sizing Guidelines.
- For Replacement End Caps, visit fhc-usa.com and search for Item No. R25TEC
2-1/2" LOW PROFILE TAPERED & SQUARE DOOR RAILS 35-3/4" LENGTH - STOCK PRODUCTS READY TO SHIP
FOR 5/8" & 11/16" GLASS FOR 5/8" & 11/16" GLASS FOR 3/4" & 13/16" GLASS FOR 3/4" & 13/16" GLASS
WITHOUT LOCK WITH LOCK WITHOUT LOCK WITH LOCK
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
R25T58XX (Tapered) R25T58XXL (Tapered) R25T34XX (Tapered) R25T34XXL (Tapered)
R25S58XX (Square) R25S58XXL (Square) R25S34XX (Square) R25S34XXL (Square)

CUSTOM LENGTH AND/OR FINISH ( ) 2-1/2" LOW PROFILE TAPERED DOOR RAILS - MANUFACTURED TO CUSTOMER SPECIFICATIONS
*
FOR 5/8" & 11/16" GLASS FOR 5/8" & 11/16" GLASS FOR 3/4" & 13/16" GLASS FOR 3/4" & 13/16" GLASS
WITHOUT LOCK WITH LOCK WITHOUT LOCK WITH LOCK
ITEM NO. ITEM NO. ITEM NO. ITEM NO.
R25T58XXC (Tapered) R25T58XXLC (Tapered) R25T34XXC (Tapered) R25T34XXLC (Tapered)
R25S58XXC (Square) R25S58XXLC (Square) R25S34XXC (Square) R25S34XXLC (Square)

XX Denotes Finish.
