FHC GLASS GATE SYSTEMS AND HARDWARE SECTION 7
FHC Glass Gate Patch Hardware

Dorma North American Dorma North American
®
®
Top Door Patch Fitting Bottom Door Patch Fitting
- For 3/4" Tempered Glass - For 3/4" Tempered Glass
- For 2-3/4" Pivot Setback - For 2-3/4" Pivot Setback
- Requires One 13/16" Diameter Hole - Requires One 13/16" Diameter Hole
and Corner Notch in Glass and Corner Notch in Glass

6-7/16"
2"

2"
6-7/16"

ITEM NO. FINISH ITEM NO. FINISH
PF2034BS Brushed Stainless PF1034BS Brushed Stainless
PF2034PS Polished Stainless PF1034PS Polished Stainless
Minimum Order: 1 Each. Minimum Order: 1 Each.

Dorma Bottom Patch Lock Dorma Transom Mount Patch Fitting
®
®
With Two Door Stops
- For 3/4" Tempered Glass
- High Density Cast Body With Lock Mechanism
- For 3/4" Tempered Glass
- Two Architectural Finishes Available - Doors Can Swing Either In or Out
- Requires One 13/16" Diameter Hole - Requires Two 13/16" Diameter Holes in Glass
and Corner Notch in Glass

4-9/16"
6-1/8"

2-5/8"
2"

5/8" Dia.
11/16" Length

Cylinder/Thumbturn
ITEM NO. PF215CT
ITEM NO. FINISH Sold Separately ITEM NO. FINISH
PF21534BS Brushed Stainless PF7034BS Brushed Stainless
PF21534PS Polished Stainless PF7034PS Polished Stainless
Minimum Order: 1 Each. Minimum Order: 1 Each.
