FHC FRAMELESS GLASS RAILING CAP RAILS, GASKETS & ACCESSORIES SECTION 2

FHC Stainless Steel Cap Rails

FHC Flat End Caps
1/8"
for Roll Formed
FOR SC15 1-1/2" SQUARE CAP RAIL
Square Cap Rails ITEM NO. FINISH
SC15ECBS Brushed Stainless
- 316 Alloy
SC15ECPS Polished Stainless
- Adhere With LT32629 Cement
and LT7649 Primer (See Pg. 53) Minimum Order: 1 Each.
FOR SC20 2" SQUARE CAP RAIL
ITEM NO. FINISH
SC20ECBS Brushed Stainless
SC20ECPS Polished Stainless
Minimum Order: 1 Each.

FHC Wall Mount End Caps for
1/8"
Roll Formed Square Cap Rails
Wall Mount FOR SC15 1-1/2" SQUARE CAP RAIL
End Cap
- 316 Alloy ITEM NO. FINISH
- Includes 1/4" x 2" Lag Bolt With Grommet SC15WCBS Brushed Stainless
- Adhere With LT32629 Cement SC15WCPS Polished Stainless
and LT7649 Primer (See Pg. 53) Minimum Order: 1 Each.
Lag Bolt With
Grommet
FOR SC20 2" SQUARE CAP RAIL
1/2" Glass
Clearance ITEM NO. FINISH
Required SC20WCBS Brushed Stainless
ITEM NO. WMBOLT1 SC20WCPS Polished Stainless
Mounting Bolt and Spacer Minimum Order: 1 Each.
Minimum Order 1 Each
FHC Square Roll Formed Cap
Rail Connector Sleeves

- For Use With Square Cap Rails
- 5" Long Used To Connect and
Align Two Pieces of Cap Rail
- Adhere With LT32629 Cement
and LT7649 Primer (See Pg. 53)
- Mill Stainless Steel
- 316 Alloy ITEM NO. DESCRIPTION
SC15CSS For 1-1/2" Square Cap Rail
SC20CSS For 2" Square Cap Rail
Minimum Order: 1 Each.

FHC Rubber Gasket for SC15 Cap Rail FHC Rubber Gasket for SC20 Cap Rail
- Securely Attaches Glass to Cap Rail - Securely Attaches Glass to Cap Rail
- 20' Length - 20' Length
- High Quality EPDM Rubber - High Quality EPDM Rubber

Glass
15/16"
15/16" Glass Deduction
Deduction

ITEM NO. DESCRIPTION ITEM NO. DESCRIPTION
CRV6RL For 1/2", 9/16" and 5/16" Glass CRV3RL For 1/2", 9/16" and 5/8" Glass
CRV7RL For 11/16" and 3/4" Glass CRV4RL For 11/16" and 3/4" Glass
Minimum Order: 1 Roll. CRV5RL For 13/16" Glass
Minimum Order: 1 Roll.
