Page 88 - FHC FGR24R Architectural Railing Systems

SECTION 4 FHC F-SERIES HEAVY-DUTY STAINLESS STEEL POST RAILING SYSTEMS

FHC F3 Series Railing Post Components

FHC Replacement Saddles - Designed to be Used With Fixed and - Radius Saddles Compatible With 1-1/2" to 2"
Swivel Stems Round Top Rail
for F3 Series Railing Post - 90, 135, and 180 Degree Radius and - Available In Two Architectural Finishes
Flat Saddles - Includes (2) #10-32 Handrail Mounting Screws
- 316 Grade Stainless Steel
FHC Radius Saddles for Round Tubing
FHC RADIUS SADDLES
ITEM NO. ANGLE FINISH
PS1BS 180 Degree Brushed Stainless
PS1PS 180 Degree Polished Stainless
PS9BS 90 Degree Brushed Stainless
PS9PS 90 Degree Polished Stainless
3" 3" 3"
3" 3" PS3BS 135 Degree Brushed Stainless
PS3PS 135 Degree Polished Stainless
Minimum Order: 1 Each.
MODEL PS1 MODEL PS9 MODEL PS3
180 Degree Saddle 90 Degree Saddle 135 Degree Saddle
FHC Flat Saddles for Square or Rectangular Tubing
FHC FLAT SADDLES
ITEM NO. ANGLE FINISH
PF1BS 180 Degree Brushed Stainless
PF1PS 180 Degree Polished Stainless
3" 3" 3" 3" 3" PF9BS 90 Degree Brushed Stainless
PF9PS 90 Degree Polished Stainless
PF3BS 135 Degree Brushed Stainless
PF3PS 135 Degree Polished Stainless
MODEL PF1 MODEL PF9 MODEL PF3 Minimum Order: 1 Each.
180 Degree Saddle 90 Degree Saddle 135 Degree Saddle
FHC 1" X 2" Narrow Rectangular Post Fascia FHC 10-32 Thread Cutting Screw
Brackets for Center or End Post - #10-32 Thread
3/4" Long Stainless Steel
- Use With FHC PR12 1"x 2" Narrow Rectangular Pipe Rail - Used to Fasten Brackets
- For Center or End Post Applications to Handrail
- Pre Drilled With (4) 7/16" Diameter Holes - 100 Screws Per Pack
- 3-1/2" Wide X 6-1/2" Tall Mounting Base, 3/8" Thick
- Available in Two Architectural Finishes
3/8" ITEM NO. HB10X32TC
Minimum Order 1 Pack
3-1/2"

®
Loctite Clear
Poxy-Pak
Two-Part Epoxy
- Sets in 5 Minutes
- Full Strength in One Hour
6-1/2" - Bonds Virtually Any
Material
- High Temperature
Resistance
- Repairs, Fills and Seals
Holes, Cracks and Worn
Surfaces
- Sandable and Paintable

ITEM NO. FINISH
FB12BS Brushed Stainless
FB12PS Polished Stainless ITEM NO. LT1324007
Minimum Order: 1 Each. Minimum Order 1 Each
Loctite is a registered trademark of Henkel Corporation
visit fhc-usa.com to search for
Railing Posts
THE GLAZING SUPPLY COMPANY
Enter the Item Number or scan QR code with
74 EXPERIENCE AND INNOV A TION your smartphone for complete product details
