SECTION 1
SECTION 1 FHC PREMIUM ALUMINUM RAILING SYSTEMS
FHC X2 | X3 | X35 | X4 | NEW X9 Premium AR Systems
FHC X2 | X3 |

X35 | X4 | X9 1

AR Series Outside & Inside 90 Degree
Fascia Mount Post Kits
- Fascia Mount Bracket for 8 7 3
2-3/8" Square AR Post 2
- For Inside and Outside 90
Degree Post Configurations
- Two Standard Post Heights
- Includes Post, Gaskets, Bottom
Cap, Washers and Buttons
- Available in Four Standard 4
Colors and Mill Aluminum
- Top Rail, Bottom Rail and 5
Glazing Vinyl Sold Separately
36" Inside & 6
Outside Post Kits 7 WORKS WITH X9 SPYGLASS SERIES
ITEM NO. X9T20XX
ITEM NO. F9136KXX X9 Spyglass Top Rail
Inside 90 Degree Fascia (See Page 44)
47" Post Length
Minimum Order: 1 Each. ITEM NO. X9BR20XX
X9 Series 2 Piece Bottom Rail
ITEM NO. F936KXX WORKS WITH (See Page 44)
Outside 90 Degree Fascia ITEM NO. X2T20XX
47" Post Length X2 Tahoe Top Rail KIT COMPONENTS
Minimum Order: 1 Each. (See Page 46) 1 SP20XX 135 Degree AR Post Extrusion
42" Inside & ITEM NO. X3T20XX 2 FMB90XX Outside Fascia Post
X3 Sierra Top Rail
and Bottom Cover Kit
Outside Post Kits (See Page 46) Inside Fascia Post
ITEM NO. X35T20XX 3 FMB91XX and Bottom Cover Kit
ITEM NO. F9142KXX X35 Everest Top Rail 4 BPS516 5/16" Base Plate Screw
Inside 90 Degree Fascia (See Page 46)
53" Post Length ITEM NO. X4T20XX 5 FBPS8 Fascia Bracket Screws
Minimum Order: 1 Each. X4 Fiji Top Rail
(See Page 46) 6 BN1XX Plastic Snap-On Button
ITEM NO. F942KXX ITEM NO. BRG20XX 7 WSH1 Stainless Steel Washer
Outside 90 Degree Fascia Bottom Rail With
53" Post Length Glass Infill 8 BPG8BL (FMB90) 6" Long Black Gasket
BPG6BL (FMB91)
Minimum Order: 1 Each. (See Page 48)
FHC Fascia Mount 90 .100 Wall Thickness
Degree Post Only

- 2-3/8" Square AR Post Only .25
- Available in Four Standard Wall
Colors and Mill Aluminum 2-3/8" Thickness
- Custom Heights and
Finishes Available
FASCIA MOUNT
2-3/8"
Available Finishes
X2, X3, X35, X4, X9 SERIES 90 DEGREE FASCIA MOUNT POST ONLY
ITEM NO. DESCRIPTION POST HEIGHT/LENGTH
F36XX 2-3/8" Square AR Fascia Post 47"
F42XX 2-3/8" Square AR Fascia Post 53"
SP20XX 2-3/8" Square AR Fascia Post 241"
W BRZ MB S M Minimum order: 1 each.
TRAFFIC DARK MATTE SILVER MILL ALUMINUM
WHITE BRONZE BLACK METALLIC (Unpainted)
XX Denotes Finish.
Visit fhc-usa.com to search for
THE GLAZING SUPPLY COMPANY 90 Degree Post
Enter the Item Number or scan QR code with
60 EXPERIENCE A ND INNO V A TION your smartphone for complete product details
