FHC FRAMELESS GLASS RAILINGS SECTION 1
FHC ACHIEVE FGR Frameless Glass Railing System
®

FHC End Caps for ACHIEVE
®
A1M Series Base Shoes

- Fits A1M Series Base Shoe
- Install With CT040 High-Bond
Tape or S790BL Silicone
(See Page 28)
- Custom End Cap Sizes and

Powder Coat Finishes Available, 4-3/16"
Contact FHC Technical Sales
for a Quote

3"
ICC
ITEM NO. DESCRIPTION FINISH
AEC1BS End Cap for A1M ACHIEVE ® Base Shoe Brushed Stainless
AEC1PS End Cap for A1M ACHIEVE ® Base Shoe Polished Stainless
AEC1SA End Cap for A1M ACHIEVE ® Base Shoe Satin Anodized
AEC1MB End Cap for A1M ACHIEVE ® Base Shoe Matte Black ESR-4814
Minimum Order: 1 Each.
FHC End Caps for ACHIEVE FHC End Caps for ACHIEVE
®
®
A3M Series Base Shoes A5M Series Base Shoes
- Fits A3M Series Base Shoe - Fits A5M Series Base Shoe
- Install With CT040 High-Bond - Install With CT040 High-Bond
Tape or S790BL Silicone Tape or S790BL Silicone
(See Page 28) (See Page 28)
- Custom End Cap Sizes - Custom End Cap Sizes
and Powder Coat Finishes and Powder Coat Finishes
Available, Contact FHC 4-3/16" Available, Contact FHC 4-3/16"
Technical Sales for a Quote Technical Sales for a Quote

3-3/16" 3-5/16"
ITEM NO. DESCRIPTION FINISH ITEM NO. DESCRIPTION FINISH
AEC5BS End Cap for A5M ACHIEVE ® Base Shoe Brushed Stainless
AEC3BS End Cap for A3M ACHIEVE ® Base Shoe Brushed Stainless
AEC3PS End Cap for A3M ACHIEVE ® Base Shoe Polished Stainless AEC5PS End Cap for A5M ACHIEVE ® Base Shoe Polished Stainless
AEC3SA End Cap for A3M ACHIEVE ® Base Shoe Satin Anodized AEC5SA End Cap for A5M ACHIEVE ® Base Shoe Satin Anodized
AEC3MB End Cap for A3M ACHIEVE ® Base Shoe Matte Black AEC5MB End Cap for A5M ACHIEVE ® Base Shoe Matte Black
Minimum Order: 1 Each.
Minimum Order: 1 Each.
FHC ACHIEVE FHC ACHIEVE 1/4"
®
®
One Seal Gasket Spacer Block
With Adhesive
- Patent Pending Design Allows for

Outside Gasket to Be Set Before - Used as a Spacer
Glass is Installed Between Glass Panels 3"
- Same Profile is Used on the - 100 Per Box
Inside and Outside of Shoe
- Made From Silicone Coated Adhesive
Durable Black EPDM Material
Available in Two Lengths: ITEM NO. ROLL LENGTH
250' and 500' Rolls 1SGA250 250' 1-1/4"
1SGA500 500'
Minimum Order: 1 Roll. ITEM NO. SBA7
For A1M, A3M, A5M Series Base Shoe
