SECTION 2 FHC FRAMELESS GLASS RAILING CAP RAILS, GASKETS & ACCESSORIES
FHC Stainless Steel Cap Rails

FHC CRVG8 V-CUT Cap Rail
- For 13/16" Glass
- Cap Rail For Guardrail Systems
- V-Cut Design with 1/8" Radius Corners
- Linear Hairline Brushed Finish (304 Alloy)
- Rubber Gasket, End Caps, Corners and Factory V-Cut
Sleeves Sold Separately Corners For
- Custom Fabrication Available, Contact Tight Radius
FHC Technical Sales for More Information

Heavy-Duty 11GA.
Stainless Steel
1-5/16"
R1/8"
Linear
Brushed
Stainless
See Page 45 Finish Shown Polished
1-5/16" for Glass Deduct Stainless
Finish Shown
Chat With FHC On Our Website ICC
to Get Real Time Expert Support
from Knowledgeable Reps
ITEM NO. LENGTH FINISH
CRVG8BS 144" Brushed Stainless Chat With Us!
CRVG8PS 144" Polished Stainless ESR-4814
Minimum Order: 1 Each. Must Ship Common Carrier.

FHC 90 Degree Horizontal FHC 135 Degree Horizontal
CRVG8 V-CUT Cap Rail Corner CRVG8 V-CUT Cap Rail Corner

- Pre Fabricated 90 Degree - Available in Two - Pre Fabricated 135 Degree - Available in Two
Horizontal Corner Architectural Finishes Horizontal Corner Architectural Finishes
- For 13/16" Glass - Custom Fabrication Services - For 13/16" Glass - Custom Fabrication Services
- 6" x 6" O.D. Outer Legs Available. Contact FHC - 6" x 6" O.D. Outer Legs Available. Contact FHC
- 304 Alloy Stainless Steel Technical Sales for a Quote - 304 Alloy Stainless Steel Technical Sales for a Quote
- Use With CRVG8CSS - Use With CRVG8CSS
Connector Sleeve Connector Sleeve
6" 6"
6" 6"

90˚ 135˚
Top View Top View

Factory Welded,
Factory Welded,
Ground and Finished Ground and Finished
Corners
Corners
FOR CRVG8 V-CUT CAP RAIL FOR CRVG8 V-CUT CAP RAIL
ITEM NO. FINISH ITEM NO. FINISH
CRVG8HBS Brushed Stainless CRVG8H3BS Brushed Stainless
CRVG8HPS Polished Stainless CRVG8H3PS Polished Stainless
Minimum Order: 1 Each. Minimum Order: 1 Each.
ICC-ES is a registered trademark of ICC Evaluation Service LLC.
visit fhc-usa.com to search for
THE GLAZING SUPPLY COMPANY Cap Rail
44 EXPERIENCE AND INNOV A TION Enter the Item Number or scan QR code with
your smartphone for complete product details
