Page 120 - FGR26-Frameless-Glass-Railing

SECTION 5 FHC HANDRAILS, BRACKETS, & COMPONENTS
FHC Handrail Brackets

FHC Melrose Series
Glass Mounted Handrail Bracket
- For 1/2" - 13/16" Glass Thickness Mounting Screws
- For 1-1/2" Diameter Handrail ITEM NO. HB10X32TC
Included
- Includes (2) #10-32 Thread Cutting Screws
- Flat Adapter Saddle Sold Separately C L
- 316 Grade Stainless Steel 2-1/4" 3/4" Diameter
Hole
In Glass
1/2" Required
1-7/8"
ITEM NO. FINISH
HB6GBS Brushed Stainless C L 3/4" 2"
HB6GPS Polished Stainless Flat Saddle
HB6GMB Matte Black
ITEM NO. HBFS1
Minimum Order: 1 Each.
Included
FHC Melrose Series
Wall Mounted Handrail Bracket
Mounting Screws
- For 1-1/2" Diameter Handrail ITEM NO. HB10X32TC
- Includes (1) 3/8" - 16 Hanger Bolt Included
- Includes (2) #10-32 Thread Cutting Screws C L
- Flat Adapter Saddle Sold Separately 2-1/4" 3/8" - 16
- 316 Grade Stainless Steel 2-1/2" Long
Hanger Bolt
1/2"
1-7/8"

ITEM NO. FINISH C L 3/4" 2"
HB6WBS Brushed Stainless
HB6WPS Polished Stainless Flat Saddle
HB6WMB Matte Black
ITEM NO. HBFS1
Minimum Order: 1 Each.
Included
FHC Melrose Series
Post Mounted Handrail Bracket
Mounting Screws
- For 1-1/2" - 2" Diameter Handrail C L ITEM NO. HB10X32TC
- Includes Adapter for Round or Flat Post 2-1/4" Included
- Includes (2) #10-32 Thread Cutting Screws
- Flat Adapter Saddle Sold Separately
- 316 Grade Stainless Steel 1/2" Includes Flat
and Coped
Adapter for
1-7/8" 1.9" O.D. Post
With 3/8" - 16
Mounting Stud
C L 3/4"
ITEM NO. FINISH
HB6PBS Brushed Stainless
HB6PPS Polished Stainless Flat Saddle
HB6PMB Matte Black ITEM NO. HBFS1
Minimum Order: 1 Each. Included
Visit fhc-usa.com to search for
THE GLAZING SUPPLY COMPANY Handrail Brackets

118 EXPERIENCE AND INNOV A TION Enter the Item Number or scan QR code with
your smartphone for complete product details
