SECTION 1 FHC FRAMELESS GLASS RAILINGS
FHC ACHIEVE FGR Frameless Glass Railing System Components
®
FHC End Caps for ACHIEVE A1M FHC End Caps for ACHIEVE A3M
®
®
Series Base Shoes Series Base Shoes
- Fits A1M Series Base Shoe - Fits A3M Series Base Shoe
- Install With CT040 High-Bond - Install With CT040
Tape or S790BL Silicone High-Bond Tape or
(See Page 47) 4-3/16" S790BL Silicone

- Custom End Cap Sizes and (See Page 47) 4-3/16"
Powder Coat Finishes Available, - Custom End Cap Sizes
Contact FHC Technical Sales and Powder Coat Finishes
for a Quote Available, Contact FHC
Technical Sales for a Quote
3"
END CAP FOR A1M ACHIEVE ® BASE SHOE 3-3/16"
ADHESIVE BACK END CAP SCREW IN END CAP FINISH END CAP FOR A3M ACHIEVE ® BASE SHOE
ITEM NO. ITEM NO. ADHESIVE BACK END CAP SCREW IN END CAP
AEC1BS A1SECBS Brushed Stainless ITEM NO. ITEM NO. FINISH
AEC1PS A1SECPS Polished Stainless AEC3BS A3SECBS Brushed Stainless
AEC1SA A1SECSA Satin Anodized AEC3PS A3SECPS Polished Stainless
AEC1MB A1SECMB Matte Black AEC3SA A3SECSA Satin Anodized
AEC1M --- Mill Aluminum AEC3MB A3SECMB Matte Black
Minimum Order: 1 each. Minimum Order: 1 each.
FHC End Caps for ACHIEVE A5M FHC End Caps for ACHIEVE A6M
®
®
Series Base Shoes Series Base Shoes
- Fits A5M Series Base Shoe - Fits A6M Series Base Shoe
- Install With CT040 High-Bond - Install With CT040 High-Bond
Tape or S790BL Silicone Tape or S790BL Silicone
(See Page 47) (See Page 47)
- Custom End Cap Sizes 4-3/16" - Custom End Cap Sizes 4-3/16"
and Powder Coat Finishes and Powder Coat Finishes
Available, Contact FHC Available, Contact FHC
Technical Sales for a Quote Technical Sales for a Quote

3-5/16" 3-5/16"
END CAP FOR A5M ACHIEVE ® BASE SHOE END CAP FOR A5M ACHIEVE ® BASE SHOE
ADHESIVE BACK END CAP SCREW IN END CAP ADHESIVE BACK END CAP SCREW IN END CAP
ITEM NO. ITEM NO. FINISH ITEM NO. ITEM NO. FINISH
AEC5BS A5SECBS Brushed Stainless AEC6BS A5SECBS Brushed Stainless
AEC5PS A5SECPS Polished Stainless AEC6PS A5SECPS Polished Stainless
AEC5SA A5SECSA Satin Anodized AEC6SA A5SECSA Satin Anodized
AEC5MB A5SECMB Matte Black AEC6MB A5SECMB Matte Black
AEC5DU --- Dark Bronze Anodized AEC6DU --- Dark Bronze Anodized
Minimum Order: 1 each. Minimum Order: 1 each.
FHC ACHIEVE FHC ACHIEVE 1/4"
®
®
One Seal Gasket Spacer Block
With Adhesive
- Patent Pending Design Allows for

Outside Gasket to be set Before - Used as a Spacer
Glass is Installed Between Glass Panels 3"
- Same Profile is Used on the - 100 Per Box
Inside and Outside of Shoe
- Made From Silicone Coated Adhesive
Durable Black EPDM Material ITEM NO. ROLL LENGTH
Available in Two Lengths: 1SGA250 250' 1-1/4"
250' and 500' Rolls 1SGA500 500'
Minimum Order: 1 roll. ITEM NO. SBA7
For A1M, A3M, A5M Series Base Shoe
