FHC FRAMELESS GLASS RAILINGS SECTION 1
FHC Traditional Glass Railing System

FHC T5M

Tempered and Laminated Series
Supports 1/2" to 9/16"
Glass
Traditional Base Shoe
FHC’s Innovative Patent
Pending “One Seal” 1SGM - FHC’s Wet Glazed Aluminum Base Shoe
Dual Purpose Gasket. Now - Compatible With 1/2" Monolithic and
You Can Pre-Load or Roll in 9/16" Laminated Tempered Glass Applications
the Same Gasket - New Design - 40% Lighter Than
ICC (See Page 23) Traditional Base Shoes
- 10' and 20' Stock Lengths Drilled or Undrilled
- Designed for Heavy Glass Railing and
Windscreen Applications
“Innovative” FHC’s Tested - Custom Fabrication Services Available
ESR-4814 and Engineered Profile - 6063-T5 Aluminum Alloy
is 40% Lighter Than
Traditional Base Shoes - FHC’s Innovative “One Seal” 1SGM Series
Gasket Makes Installations Easy. Installers
Can Pre-Load Gasket Before Setting Glass
Continuous and Use the Same Gasket on the Inside to
End Cap Finish the Installation
Screw Race
ITEM NO. HY270
Hilti Injectable Mortar
®
Field Drilling Base Shoe Adhesive for Use
Just Got Easier With Our With 9/16" Tempered
Engineered Hollow Profile
Design On All Base Shoe Laminated Glass
Profiles
T5M SERIES TRADITIONAL ALUMINUM BASE SHOE
ITEM NO. DESCRIPTION
T5M10 Undrilled 120" Long
T5M10D Bottom Drilled 12" C.T.C. 120" Long
T5M10F Fascia Drilled 12" C.T.C. 120" Long
T5M20 Undrilled 240" Long
T5M20D Bottom Drilled 12" C.T.C. 240" Long ITEM NO. BSSB12 Item No. KS50 Item No. RK50
T5M20F Fascia Drilled 12" C.T.C. 240" Long Base Shoe Expansion Cement Expansion Cement
Setting Blocks Exterior Grade for Interior Grade for
Minimum Order: 1 Each. Must Ship Common Carrier.
Monolithic Glass Monolithic Glass
1" 1" 1"

4-1/8"

4-1/8" 4-1/8" 9/16" 7/8"

7/8"

13/16" 13/16" 13/16"

9/16"
2-1/2" 2-1/2" 2-1/2"
Undrilled Profile D Profile F Profile
Bottom Drilled and Counterbored Fascia/Side Drilled and Counterbored
12" on Center 12" On Center
