Item No
ML100B3RKSB

FHC Magnalink Egress Device - B Exterior Pull Handle - RHR - Rail Mount - Exterior Keyed Access - Satin Brass

Unit Of Measure EA
Please log in to view the stock status.

Minimum Order Quantity: 1

Existing Customers Can Sign in to See Pricing and Place Orders
New to FHC? Request an Account
For Non-Related Industries Dealer Referral

Features, Advantages, and Benefits

  • No Unsightly Wire Loops
  • Handle Operation is Magnetically Coupled to the Header Mounted Actuator, Creating An Invisible Connection that Eliminates the Need for Electrical Current in the Door Handle
  • Easy to Electrify, Only 2 Wires are Required for Connection to the Header Mounted Stop/Actuator
  • Tamper-Proof
  • 3 Terminals Permit Normally Open and Normally Closed Connection
  • High Current Handling Capacity Enables Direct Operation of Magnetic Locks
  • 24VDC/VAC 4A (Resistive) SPDT Switch Rated at 1,000,000 Mechanical Operations
  • Switch Has a Built-In Magnetic Blowout Feature That Protects the Contacts from Arc Erosion
  • Easily Interfaces With Complex Security Systems
  • Door Handle Has an Exact Appearance Match With FHC Steincraft™ HP100 Panic Handles
  • All Steincraft™ HP100 Exterior Pull Configurations and Finishes Are Available
  • System Uses SDC® Hi/Shear® Concealed Electromagnetic Locks and SDC® Low Voltage Power Supply 1 and 2 Amp 12/24VDC Class 2
Request a Quote
Add to Project Materials List
More Information
Product NameFHC Magnalink Egress Device - B Exterior Pull Handle - RHR - Rail Mount - Exterior Keyed Access - Satin Brass
Item NoML100B3RKSB
Weight0.000000
Select Your Color/FinishSatin Brass
HandingRHR
Compare ToEG100B3RKSB
Minimum Order Quantity1
Exterior HandleB
Mount OptionRail
Panic Handle FinishSatin Brass
Locking OptionExterior Keyed Access

WARNING: This Product May Contain Chemicals Known to the State of California to Cause Cancer or Reproductive Harm. To Learn More Visit P65Warnings.ca.gov
